Resources and Downloads
You may download the RBT-001 user manual, example source codes, PC applications, and mobile phone
application from www.parallax.com.
*Mobile phone must be compatible with the JSR-82 Java API; usually all Nokia and Sony Ericsson phone
are compatible, but check users manual for compatibility. Configuration of mobile phone is not supported
by Parallax Technical Support.

Device Information

Theory of Operation
Bluetooth is an open wireless protocol for exchanging data over short distances from fixed and mobile
devices, creating Personal Area Networks (PANs). It was originally conceived as a wireless alternative to
RS232 data cables. It can connect several devices, overcoming problems of synchronization.
There are various versions of Bluetooth communication and the Easy Bluetooth is compatible with
versions 1.x and 2.0.
Precautions
The Easy Bluetooth uses the microwave radio frequency spectrum in the 2.4 GHz to 2.4835 GHz range.
Maximum power output from this Bluetooth radio 2.5 mW; Class 2 devices are considered less of a
potential hazard than mobile phones.
Pin Definitions and Ratings
Pin
Name
1
Vss
2
RX
3
TX
4
NC
5
NC
6
NC
7
NC
8
NC
9
NC
10
Vdd

Communication Protocol

UART Command/Data Port supports up to 921.6k non-inverted baud.
Copyright © Parallax Inc.
Ground
Receive Serial Communication (CMOS & TTL Level Compatible)
Transmit Serial Communication (CMOS & TTL Level Compatible)
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
Not Connected
+3.3 to +5 VDC (+5.5 max voltage)
Easy Bluetooth (#30085)
Function
v1.3 4/14/2010 Page 4 of 9
