COLOUR TELEVISION
INSTRUCTIONS
Thank you for buying this JVC
colour television.
To make sure you understand how to
use your new TV, please read this
manual thoroughly before you begin.
AV-20N83
AV-21D83
AV-25K83
LCT1204-001A-H
1002-NIC-JET
Contents
3 Connecting the aerial and VCR .................. 4
4 Connecting other devices .......................... 5
6 Initial setting ............................................... 6
ECO SENSOR button ..................................... 8
PICTURE MODE button ................................. 8
COLOUR SYSTEM button ............................. 8
SOUND SYSTEM button ............................... 8
button ....................................................... 9
PICTURE BOOSTER button ........................... 9
MUTING button ............................................. 9
DISPLAY button ............................................. 9
OFF TIMER button ......................................... 9
RETURN + button ........................................ 10
CHANNEL SCAN button .............................. 10
CINEMA SURROUND button ...................... 10
Basic operation ............................................ 11
INPUT ........................................................... 12
VNR ............................................................... 12
COMPRESS (16:9) ........................................ 12
AUTO SHUTOFF .......................................... 13
CHILD LOCK ................................................. 13
BLUE BACK .................................................. 13
VIDEO-2 SET ................................................ 14
AUTO CH PRESET ....................................... 14
MANUAL CH PRESET .................................. 15
SKIP .............................................................. 16
LANGUAGE .................................................. 16
Picture Adjustments .................................... 17
Sound Adjustments ..................................... 17
AI VOLUME .................................................. 17
© 2002 VICTOR COMPANY OF JAPAN, LIMITED
2
3
7
11
18
20
21
22
Advertisement
Table of Contents
Related Manuals for JVC AV-20N83
Summary of Contents for JVC AV-20N83
-
Page 1: Table Of Contents
COLOUR TELEVISION INSTRUCTIONS Thank you for buying this JVC colour television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. AV-20N83 AV-21D83 AV-25K83 LCT1204-001A-H 1002-NIC-JET Contents Safety precautions Preparation 1 Confirm which remote control you have ... 3 2 Insert the batteries into the remote control ... -
