COLOUR TELEVISION
AV-14A10
AV-14F10
AV-20N10
AV-21A10
AV-21D10
AV-21F10
INSTRUCTIONS
Thank you for purchasing this JVC
colour television.
To ensure your complete
understanding, please read this
manual thoroughly before operation.
CAUTION:
• TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES
REGARDING THE USE OF THIS TV.
• Operate only from the power source specified on the TV.
• Avoid damaging the power plug and power cord.
• Avoid improper installation and never position this TV where good ventilation is
unattainable. When installing this TV
distance recommendations must be
maintained between the floor and
wall, as well as installment in a tightly
enclosed area or piece of furniture.
Adhere to the minimum distance
guidelines shown for safe operation.
• Do not allow objects or liquid into the cabinet openings.
• In the event of a fault, unplug this TV and call a service technician. Do not
attempt to repair it by yourself or remove the rear cover.
• When you don't use this TV for a long period of time, be sure to disconnect the
power plug from the AC outlet.
Contents
Locations ................................
Preparation .............................
Basic operation ......................
and functions ........................
Using the TV's menus ..........
Troubleshooting ...................
Specifications .......................
WARNING:
TO PREVENT FIRE OR SHOCK
HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR
MOISTURE.
10 cm
10 cm
2
3
9
10
13
16
18
19
15 cm
15 cm
Advertisement
Table of Contents
Related Manuals for JVC AV-14A10,AV-14F10, AV-20N10, AV-21A10, AV-21D10, AV-21F10
Summary of Contents for JVC AV-14A10,AV-14F10, AV-20N10, AV-21A10, AV-21D10, AV-21F10
-
Page 1: Table Of Contents
AV-14A10 AV-14F10 AV-20N10 AV-21A10 AV-21D10 AV-21F10 INSTRUCTIONS Thank you for purchasing this JVC colour television. To ensure your complete understanding, please read this manual thoroughly before operation. CAUTION: • TO ENSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES REGARDING THE USE OF THIS TV. -
Page 2: Locations
Locations RM-C364GY SENSOR SYSTEM COLOUR SOUND TV/VIDEO TIMER CHANNEL RETURN SCAN DISPLAY MENU CHANNEL VOLUME REMOTE CONTROL UNIT RM-C364GY ECO SENSOR button SOUND SYSTEM button COLOUR SYSTEM button TV/VIDEO button OFF TIMER button CHANNEL SCAN button RETURN + button DISPLAY button CHANNEL –/+ buttons POWER PICTURE... -
Page 3: Preparation
Preparation 1. Connecting the aerial and external devices Notes: ... • For further details, refer to the manuals provided with the devices you are connecting. • Connecting cables are not supplied. • The front and rear AUDIO/VIDEO input jacks are directly connected so that input to either jack is output through both. -
Page 4: Connecting Other External Devices
Preparation I Connecting other external devices VIDEO • Illustration of AV-21D10. Headphones Note: ... • Use the headphones with a stereo mini jack (3.5 mm in diameter). When you connect the headphones, the TV speakers go off. To audio output VCR (for playing) AUDIO VCR (for recording) -
Page 5: Connecting The Power Cord
2. Connecting the power cord Insert the Power plug into an AC outlet. 3. Inserting batteries into the remote control Correctly insert two batteries, observing the end first. 4. Turning your TV on Press the Main power button on the TV to turn the TV’s main power The POWER lamp or POWER/ON TIMER lamp lights. -
Page 6: Presetting Tv Stations
Preparation 5. Selecting the on-screen language You can select the language for the on-screen display. Press MENU then select LANGUAGE . Press MENU –/+ to select language. The on-screen displays indications are in the selected language. 6. Presetting TV stations To view a TV programme, you must first preset TV channels to channels on the TV. - Page 7 I Manual Channel Preset You can manually preset the desired TV channels to the desired channels. Press MENU to display the MENU 3 menu, then select MANUAL CH PRESET . Press MENU –/+. The sub-menu is displayed. • The channel No. is displayed as a PR No. Press MENU –/+ to select the channel number.
- Page 8 Preparation I Skip You can set undesired channels to be skipped. Channels set to be skipped cannot be selected by the CHANNEL –/+ buttons nor the CHANNEL SCAN button. • Channels to which a station has not been preset are automatically set to be skipped. Press MENU PRESET .
-
Page 9: Basic Operation
Basic operation POWER SENSOR SYSTEM PICTURE COLOUR SOUND MODE TV/VIDEO TIMER CHANNEL RETURN SCAN DISPLAY MUTING MENU CHANNEL VOLUME REMOTE CONTROL UNIT RM-C364GY Press the POWER button to turn your TV on. • If your TV does not turn on, press the Main power button on the TV then press the POWER button again. -
Page 10: Remote Control Buttons And Functions
Remote control buttons and functions Colour System If the colour is abnormal, select the appropriate colour system. Each press of the COLOUR SYSTEM button changes the colour system as follows. In TV mode (channel 1 to 99 and AV): AUTO In VIDEO mode: AUTO NTSC3.58... -
Page 11: Off Timer
Display You can continuously display the current channel number or VIDEO mode on the screen. Press the DISPLAY button. To turn the display off, press the DISPLAY button again. • When selecting a channel or VIDEO mode with no input signal, indication of selected channel or VIDEO mode becomes fixed on the screen. -
Page 12: Channel Scan
Remote control buttons and functions Channel Scan You can search for the channel you want to view while scanning all of the channels that can be viewed on this Press CHANNEL SCAN. Channels will be scanned in channel No. order. When the channel that you want to view appears, press CHANNEL SCAN again... -
Page 13: Using The Tv's Menus
Using the TV’s menus On Timer Your TV will automatically turn on and tune into the channel you set after the period of time you set. Press MENU to display the MENU 1 menu, then select ON TIMER . MENU INPUT Channel ON TIMER... -
Page 14: Auto Shutoff
Using the TV’s menus (Video Noise Reduction) You can reduce the picture noise. Press MENU the MENU 1 menu, then select VNR . MENU INPUT ON TIMER PR 1 0:00 SELECT BY EXIT BY OPERATE BY -+ D I SPLA Y Press MENU –/+ to select ON . -
Page 15: Blue Back
Blue Back You can mute the sound and change the picture into a blue screen while no signals are received by the TV, or when the signals are unstable. Press MENU to display the MENU 2 menu, then select BLUE BACK . MENU AUTO SHUTOFF CHILD LOCK... -
Page 16: Using The Button On The Tv
Using the button on the TV <AV-21D10> MENU <AV-21A10> MENU <AV-14F10/AV-20N10/AV-21F10> MENU <AV-14A10> MENU 1 MENU buttons • MENU button • MENU –/+ buttons 2 CHANNEL –/+ buttons 3 VOLUME –/+ buttons 4 ON TIMER lamp The light is switched on while On Timer function is operating. - Page 17 Basic operation • Check to make sure the Child Lock function is set to OFF . When the Child Lock function is set to ON , the TV cannot be operated using the front control buttons. For details, see “Child Lock” on page 14.
-
Page 18: Troubleshooting
Troubleshooting Important: Review all the instructions in this manual. Problem Cannot turn TV on No picture nor sound Remote control inoperable Buttons on front of TV do not work The TV turns on suddenly The TV turns off suddenly Abnormal sound Abnormal colour Lines or streaks in picture (interference) -
Page 19: Specifications
Specifications TV RF systems B, G, I, D, K, K1 Colour systems PAL, SECAM, NTSC3.58/4.43MHz (in VIDEO mode only) Channel and frequencies VHF low channel (VL) VHF high channel (VH) UHF channel (U) I Receives cable channels in mid band (X to Z, S1 to S10), super band (S11 to S20) and hyper band (S21 to S41) . - Page 20 2001 VICTOR COMPANY OF JAPAN, LIMITED LCT1039-001A-H 0701-Ki-NV-JMT...
