Instructions of Door Replacement

Step 1. Remove the top
hinge cover
Step 4. Remove the middle
hinge with screwdriver
Step 7. Remove the hinge shaft
cover, middle beam hole cover,
and the adjustable feet.
Step 10. Remove the hinge bushing
and door stop of the R-door and
F-door with screwdriver, and install
them to the other side of the doors.
Step 13. Use a screwdriver to mount
the top hinge to the left side of the top
of the refrigerator
Step 2. Remove the top hinge
with screwdriver
Step 5. Remove the R-door
Step 8. Install the adjustable feet
to the right side in front of the
refrigerator; mount the lower hinge
subassembly to the left side in front
of the refrigerator
Step 11. Use a screwdriver to mount
the middle hinge to the left side of the
middle beam in front of the refrigerator
Step 14. Mount the top hinge cover to the top hinge; mount the
hinge shaft cover to the top right of the refrigerator; mount the
middle beam hole cover to the right side hole of the middle beam.
008
Step 3. Remove the F-door
Step 6. Remove the lower
hinge with screwdriver
Step 9. Remove the hinge
bushing and door stop of the
R-door and F-door with
screwdriver, and install them
to the other side of the doors.
Step 12. Install the F-door onto
the middle hinge.
