- Page 1 330157 INSTALLATION INSTRUCTIONS USER GUIDE VOGUE Integrated Rangehood 600mm To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time...
- Page 2 If you follow the recommendations contained in this Instruction Manual, our appliance will give you constant high performance and will remain efficient for many years to come. Product Specification & Technical Parameters Model 330157 Rated Voltage 220-240V Rated Power Frequency 50Hz...
-
Page 3: Recommendations And Suggestions
RECOMMENDATIONS AND SUGGESTIONS INSTALLATION * The manufacturer will not be held liable for any damages resulting from incorrect or improper installation. * Please read this instruction manual before installing and using this range hood. Please keep this instruction manual in a safe place for future reference. -
Page 4: Maintenance
NOTICE: Two or more people are required to install or move this appliance. Failure to do so can cause physical injuries. * The range hood has been designed only for domestic use to eliminate kitchen fumes. * Never use the hood for purposes other than what it has been designed for. * Never leave high naked flames under the hood when it is in operation. - Page 5 WARNING!! In certain circumstances electrical appliances may be a danger hazard. * Do not check the status of the filters while the cooker hood is operating * Do not touch the light bulbs after appliance use * Do not disconnect the appliance with wet hands. * To reduce the risk of fire or electric shock, do not use this fan with any solid-state.
- Page 6 * This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction, concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
-
Page 7: Installation And Use
INSTALLATION & USE OPERATION OF CONTROLS The hood is operated with the touch control with handsensor located on the front glass of the hood. 1-Light on/off gesture control sensor 2-Fan speed gesture control sensors When connected to the electricity, all the button light are on for one second then go off. -
Page 8: Time Delay
TIME DELAY When the motor is working, use time delay to turn off the range hood in specific time. Pressing the button timer, the range hood will be turn off automatically in 15 minutes. GESTURE CONTROL Touch speed gesture to turn gesture control on/off. You can use gestures to control the fan speed and lighting. - Page 9 Non-Ducted Recirculation charcoal filter The non-ducted recirculation charcoal filter should be changed every 6 months. See “INSTALL FILTERS” section for removal and installation instructions. INSTALL THE DUCTWORK (DUCTED HOODS ONLY) Caution: To reduce the risk of fire, use metal ductwork is preferred. 1.
-
Page 10: Install Electrical
INSTALL ELECTRICAL Electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and standards. This range hood must be properly grounded. Turn off electrical power at service entrance before wiring. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard INSTALL THE HOOD Note 1 : On stainless steel hoods, carefully remove the plastic protective film... - Page 11 INSTALL FILTERS 1. To remove the grease filter, push in on the metal latch tab. This will disengage the filter from the hood. Tilt the filter downward and remove. To install the grease filter, align aluminum filter with slots in the hood. Push in the plas�c latch tab, put the filter into posi�on and lock it until the stop click is heard.
