- Page 1 INSTALLATION INSTRUCTIONS USER GUIDE VOGUE T-Canopy Rangehood 900mm Stainless Steel / Black Fascia 330264 To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the f irst time...
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS INSTALLATION START USING YOUR RANGEHOOD TROUBLESHOOTING MAINTENANCE AND CLEANING ENVIRONMENT PROTECTION... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS This manual explains the proper installation and use of your Rangehood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. Never to do: • Do not try to use the Rangehood without the grease filters or if the filters are excessively greasy! •... - Page 4 Always to do: • Warning: Before obtaining access to terminals, all supply circuits must be disconnected. • Always put lids on pots and pans when cooking on a gas cooker. • When in extraction mode, air in the room is being removed by the Rangehood. Please make sure that proper ventilation measures are being observed.
-
Page 5: Installation
INSTALLATION (VENT OUTSIDE) MOUNTING OF THE V-FLAP If the Rangehood does not have an assembled V-flap 1, you should mount the half-parts to its body. The images only show an example of how to mount the V-flap,the outlet may be various ac- cording to different models and configuration. To mount the V-flap 1 you should: • Mount two half-parts 2 into the body 6 • A pin 3 should be top oriented; • The axis 4 should be inserted in the holes 5 on body; •... - Page 6 INSTALLATION 1. Before installation, turn the unit off and 2. The Rangehood should be placed at a distance of 65~75cm above the cooking unplug it from the outlet. surface for best effect. 3. Install the hook on a suitable place once 4. Install the v-flap and lay the expansion the installation height is fixed, and keep pipe to the outlet. Fix the expansion pipe it in line. The fixed position of the inside with the cable tie on the outlet and put chimney bracket is the highest place of...
- Page 7 WARNING For safety reason, please use only the same size of fixing or mounting screw which are recommended in this in- struction manual. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. HINTS FOR EXHAUST DUCT INSTALLATION The following rules must be strictly followed to obtain optimal air extraction: • Keep expansion pipe short and straight. •...
-
Page 8: Start Using Your Rangehood
Start Using Your Rangehood Touch control with LED display 1. Press the “Power” button, the button control the “on” & “off ” of the hood. 2. Press the button “Speed” time after time, the motor runs as low / mid / high / low / mid…, the speed runs circularly; and the LED display will indicate as 1-2-3-1-2… circularly. 3. Press “Light” button, the light is on, press this button again, the light is off. Please note the Lamp is not under control of the on/off button. -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING CAUTION: • Before maintenance or cleaning is carried out, the Rangehood should be disconnected from the main power supply. Ensure that the Rangehood is switched off at the wall socket and the plug removed. • External surfaces are susceptible to scratches and abrasions, so please follow the cleaning instructions to ensure the best possible result is achieved without damage. GENERAL Cleaning and maintenance should be carried out with the appliance cold especially when cleaning. - Page 10 INSTALLING GREASE MESH FILTERS • To install filters for the following four steps. - Angle the filter into slots at the back of the hood. - Push the button on handle of the filter. - Release the handle once the filter fits into a resting position. - Repeat to install all filters. CARBON FILTER-NOT SUPPLIED Activated carbon filter can be used to trap odors. Normally the activated carbon filter should be changed at three or six months according to your cooking habit. The installation procedure of acti- vated carbon filter is as below. 1. Before installing or replacing the carbon filters, please remove power to the unit. 2. Press the filter lock and remove the mesh filter 3. Turn the carbon filter on both side of the motor anti-clockwise. Replace the carbon filters with the new carbon filters. 4. Place the mesh filter. 5. Connect the power supply to the wall socket. NOTE • Make sure the filter is securely locked. Otherwise, it would loosen and cause dangerous.
- Page 11 BULB REPLACEMENT The bulb must be replaced by the manufacturer, its service agent or similarly qualified persons. IMPORTANT Always switch off the electricity supply before carrying out any operations on the appliance. When handling bulb, make sure it is completely cool down before any direct contact to hands. When handling globes hold with a cloth or gloves to ensure perspiration does not come in contact with the globe as this can reduce the life of the globe.
-
Page 12: Environment Protection
ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/EU.
