163
Removal
Detach RU from Wall
Flat Washer
Split Washer
Lag Bolt
Figure 58
Removing Wall Mount Plate from Wall
Step 5
Remove the Wall Mount Plate and the M10 bolts from the wall.
✓
This task is complete.
Fujitsu and Fujitsu Customer Use Only
·
Issue 1.1, May 2021
Release 1.0
