  • Page 1 CD RECEIVER CD-RECEIVER RECEPTEUR CD CD-RECEIVER KD-S6060 LOUD DISP MODE COMPACT DIGITAL AUDIO For installation and connections, refer to the separate manual. Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch. Pour l’installation et les raccordements, se référer au manuel séparé. Bijzonderheden over de installatie en aansluiting van het apparaat vindt u in de desbetreffende handleiding.

  • Page 2: How To Reset Your Unit

    IMPORTANT FOR LASER PRODUCTS 1. CLASS 1 LASER PRODUCT 2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel. 3. CAUTION: Visible and invisible laser radiation when open and interlock failed or defeated. Avoid direct exposure to beam.

  • Page 3: Table Of Contents

    Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit. CONTENTS How to reset your unit ... How to use the MODE button ...

  • Page 4: Location Of The Buttons

    LOCATION OF THE BUTTONS Control panel Display window LOUD DISP (standby/on attenuator) button 2 LOUD (loudness) button 3 SEL (select) button 4 Display window 5 Loading slot 6 0 (eject) button 7 CD button 8 AM button 9 FM button ¢/4 buttons •...

  • Page 5: Basic Operations

    LOUD DISP Turning on the power Turn on the power. Note on One-Touch Operation: When you select a source in step 2 below, the power automatically comes on. You do not have to press this button to turn on the power. Select the source.

  • Page 6: Setting The Clock

    LOUD DISP Setting the clock Press and hold SEL (select) for more than 2 seconds. “CLOCK H,” “CLOCK M,” “SCM LINK,” or “LEVEL” appears on the display. Set the hour. 1 Select “CLOCK H” (hour) if not shown on the display. CLOCK H LEVEL 2 Adjust the hour.

  • Page 7: Radio Operations

    LOUD DISP Listening to the radio You can use either automatic searching or manual searching to tune in to a particular station. Searching for a station automatically: Auto search Select the band (FM1 – 3, AM). Lights up when receiving an FM stereo broadcast with sufficient signal strength.
  • Page 8 Searching for a station manually: Manual search Select the band (FM1 – 3, AM). Note: This receiver has three FM bands (FM1, FM2, FM3). You can use any one of them to listen to an FM broadcast. ¢ or 4 Press and hold until “M”...

  • Page 9: Storing Stations In Memory

    Storing stations in memory You can use one of the following two methods to store broadcasting stations in memory. • Automatic preset of FM stations: SSM (Strong- station Sequential Memory) • Manual preset of both FM and AM stations FM station automatic preset: SSM You can preset 6 local FM stations in each FM band (FM1, FM2, and FM3).

  • Page 10: Tuning In To A Preset Station

    Press and hold the number button (in this example, 1) for more than 2 seconds. “P1” flashes for a few seconds. Repeat the above procedure to store other stations into other preset numbers. Notes: • A previously preset station is erased when a new station is stored in the same preset number.

  • Page 11: Cd Operations

    LOUD DISP Playing a CD Insert a CD into the loading slot. The unit turns on, draws the CD and starts playback automatically. Note on One-Touch Operation: When a CD is already in the loading slot, pressing CD turns on the unit and starts playback automatically.

  • Page 12: Locating A Track Or A Particular Portion On A Cd

    Locating a track or a particular portion on a CD To fast-forward or reverse the track Press and hold playing a CD, to fast-forward the track. Press and hold 4 playing a CD, to reverse the track. To go to the next or previous tracks ¢...

  • Page 13: Prohibiting Cd Ejection

    To play back tracks repeatedly (Repeat Play) You can play back the current track repeatedly. MODE Press MODE to enter the functions mode while playing a Press RPT (repeat), while still in the functions mode, so that the RPT indicator lights up on the display.

  • Page 14: Sound Adjustments

    SOUND ADJUSTMENTS Adjusting the sound You can adjust the sound characteristics to your preference. Select the item you want to adjust. Each time you press the button, the adjustable items change as follows: (bass) (treble) (volume) Indication To do: Adjust the bass. Adjust the treble.

  • Page 15: Using The Sound Control Memory (Scm)

    Using the sound control memory (SCM) You can select and store a preset sound adjustment suitable for each playback source (Advanced SCM). Selecting and storing the sound modes Once you select a sound mode, it is stored in memory. It will be recalled every time you select the same source and will be shown on the display.

  • Page 16: Storing Your Own Sound Adjustments

    Storing your own sound adjustments You can adjust the sound modes (BEAT, SOFT, POP) to your preference and store your own adjustments in memory. • There is a time limit in doing the following procedure. If the setting is canceled before you finish, start from step 1 again.

  • Page 17: Other Main Functions

    Selecting the level display —LEVEL You can select the level display according to your preference. When shipped from the factory, “VOL 2” is selected. • VOL 1: Shows the volume level indicator. • VOL 2: Alternates “VOL 1” setting and illumination display.

  • Page 18: Detaching The Control Panel

    Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on the back of the control panel and on the panel holder. Detaching the control panel Before detaching the control panel, be sure to turn off the power.

  • Page 19: Troubleshooting

    What appears to be trouble is not always serious. Check the following points before calling a service center. Symptoms • Sound cannot be heard from the speakers. • This unit does not work at all. • SSM (Strong-station Sequential Memory) automatic preset does not work.

  • Page 20: Maintenance

    MAINTENANCE Handling discs This unit has been designed to reproduce CDs and CD-Rs (Recordable). • This unit is not compatible with MP3 discs. How to handle discs When removing a disc from its case, press down the center holder of the case and lift the disc out, holding it by the edges.

  • Page 21: Specifications

    AUDIO AMPLIFIER SECTION Maximum Power Output: Front: 45 W per channel Rear: 45 W per channel Continuous Power Output (RMS): 17 W per channel into 4 Ω, 40 Hz Front: to 20 000 Hz at no more than 0.8% total harmonic distortion. 17 W per channel into 4 Ω, 40 Hz Rear: to 20 000 Hz at no more than...
  • Page 22 Having TROUBLE with operation? Please reset your unit Refer to page of How to reset your unit Haben Sie PROBLEME mit dem Betrieb? Bitte setzen Sie Ihr Gerät zurück Siehe Seite Zurücksetzen des Geräts Vous avez des PROBLÈMES de fonctionnement? Réinitialisez votre appareil Référez-vous à...

  • Page 23: Installation

    Neem bij vragen of voor meer bijzonderheden over inbouwpakketten contact op met uw JVC car audio dealer of een dealer of een bedrijf dat inbouwpakketten levert. (déblocage Voordat u aan de montage van het apparaat...

  • Page 24: Electrical Connections

    Als het geluid niet verdwijnt, moet u contact opnemen met uw JVC car audio dealer. • Het maximum ingangsvermogen van de speakers moet achterin meer dan 45 W zijn en voorin 45 W, met een impedantie van 4 Ω...
  • Page 25 ENGLISH DEUTSCH If your car is equipped with the ISO connector Wenn Ihr Auto mit ISO-Steckern ausgestattet ist Si votre voiture est équippée d’un connecteur ISO Indien uw auto is uitgerust met de ISO-connector • Connect the ISO connectors as illustrated. •...

  • Page 26: Problemen Oplossen

    Lautsprecherleitungen dieses Geräts unbenutzt lassen. (Die Anschlußklemmen dieser nicht verwendeten Leitungen mit Isolierklebeband umwickeln, siehe Abbidung oben.) Rear speakers Hintere Lautsprecher Enceintes arrière Achterspeakers JVC Amplifier INPUT JVC Verstärker JVC Amplificateur JVC Versterker LINE KD-S6060 REAR Signal cord (not supplied with this unit) Einzelleitung (nicht mit diesem Gerät...
