Atomstack A5 10W
Atomstack A5 20W
11
1. Remove the current acrylic
shields
The air
guide
hood tube
mouth is
on the left
5. Find NO.1 from the accessories.
Install it as shown
Atomstack A5 30W
Installation of Air Guide Hood for Four Models
Atomstack A5 Pro
2. Rotate the laser backward 180°
6. Tighten the self-tapping screws
with a PH1 Phillips screwdriver
3. Remove the set screw
7. Find NO.1-1 from the accessories
and install it as shown.
4. Rotate the current air guide hood
counterclockwise to remove it.
8. Insert the tube and fixed
it with a tie
