MEASUREMENT
Memory Full
When the CellScales ID Code memory is full this
screen appears if you try to enter a new ID Code.

SETUP ID CODES

Allows Front Panel setup of ID Codes features. The 8 character ID Name can be edited, two 20 character print
strings can be assigned to each ID Code, and the Numeric Display mode can be modified. In addition the display
mode for the desired ID code can be changed to a PER CENT reading or the display can be turned off.
ID NAME
The name of each ID Code can be changed as desired using the scroll keys, cursor keys, and the Alpha-numeric
keys. This menu item is not used for initial ID Code name entry (see ID CODES). If the name is edited, it
may no longer be in alphabetical order.
To Edit the current ID Code Name
1) Push SETUP.
2) Push the ID # key (whatever Fkey ID# is
assigned to). The message display reads "ID
NUMBR".
3) Press ENTER. The display reads "ID
NAME".
4) Push ENTER to go to the edit screen.
5) The message display will show the far left
character blinking. Use the LEFT / RIGHT
Cursor keys to select the character you wish
to edit. Use the UP/DOWN keys or use the
standard Alpha-Numeric entry procedure to
change the letter(s). When finished editing,
push the ENTER key twice.
See "General Alpha-Numeric Character Entry Procedure".
6) The display reads "ID NAME". Press EXIT to
return to normal weighing mode or press UP
or DOWN to reach the next selection.
Software V1-15 to 1-20
SYSTEMS INTERNATIONAL
1
ID NUMBR
2
ID NAME
3
Current ID Name appears
4
...to select char.
5
...to scroll char.
5
...to input char.
5
...to finalize edit.
5
6
®
MSI-9000 CellScale System • 3750CS User Guide
ID NAME
Page 31
