- Page 1 HAND DRYERS E05 / E05C / E05CS / E05B E05A / E05AC / E05ACS / E05AB INSTALLATION AND OPERATING MANUAL RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by...
-
Page 2: Safety Instructions
ENGLISH SAFETY INSTRUCTIONS Before to carry on any operation, please read carefully and take into account the following safety instructions: - Only a qualified technician can install, adjust and maintain this device. All this operations must be always done according to the current legal European Standards of installation and according the local installation regulations as well. -
Page 3: Installation
- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 Mounting The appliance's electrical installation is made via rear channelling (see fig. 5). • The terminal block for the power supply cable wires and their entrance hole (Ø 22 mm - Ø 0.87" -) are located on the left-hand side of the dryer.
-
Page 5: Wiring Diagram
Care must be taken during this operation not to touch the electronic circuit that is housed under the column with the cover. NOTE: a minimum distance of 40 cm (15.75") must be allowed between any possible shelves,marble or washbasins (see figure 11). As far as possible, reflecting surfaces should be avoided within the operating range of the IR sensors. - Page 6 BREAKDOWN LIST OF BASIC PARTS COMPONENT NUMBER CODE White pushbutton cover RC94810 Chrome bright pushbutton cover RC94830 Chrome satin pushbutton cover RC94820 Varnished pushbutton cover RC94813 White automatic cover RC94850 Chrome bright automatic cover RC94870 Chrome satin automatic cover...
-
Page 7: Method Of Use
ADJUST DETECTING DISTANCE The hand dryer has means to adjust manually the distance for detecting hands. These adjustments of the motor speed must be made by a qualified technician only. The adjustments can be made by moving the cursor of the linear potentiometer. METHOD OF USE To dry hands correctly, we recommend rising well to remove all traces of soap. -
Page 8: Preventive Maintenance And Cleaning
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE HAND DRYER. PREVENTIVE MAINTENANCE AND CLEANING Correct cleaning of the machine will lenghten its working life considerably. When in use, the machine will accumulate dust inside wich should be cleaned out if used regularly, at least once a year. - Page 9 ELIMINACIÓN DE RESIDUOS DE APARATOS ELÉCTRICOS Y ELECTRÓNICOS POR PARTE DE USUARIOS DOMÉSTICOS EN LA UNIÓN EUROPEA. El producto que ha adquirido ha sido diseñado y fabricado con materiales y componentes de alta calidad que pueden ser reciclados y reutilizados. Cuando vea un producto marcado con este símbolo de un contenedor de basura con ruedas tachado significa que dicho producto está...
- Page 10 MEDICLINICS, S.A. Industria, 54 E-08025 BARCELONA SPAIN Tel.: +34 934 464 700 Fax: +34 933 481 039 info@mediclinics.com 20/11/13 COD.: 94915 www.mediclinics.com RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by...
