Summary of Contents for Mediclinics Saniflow E88-UL
- Page 1 HAND DRYERS / SÉCHE-MAINS / SECADOR DE MANOS E88-UL / E88C-UL / E88CS-UL / E88A-UL / E88AC-UL E88ACS-UL / E88O-UL E88AO-UL / E85-UL / E85A-UL INSTALLATION AND OPERATING MANUAL MANUEL D’INSTALLATION ET D’UTILISATION MANUAL DE INSTALACIÓN Y UTILIZACIÓN...
- Page 2 ENGLISH INSTALLATION Dismantling for installation • Unscrew the two lockscrews with the special SANIFLOW wrench. • Remove the cover, taking care not to knock the equipment. • Handle the cover with care. Mounting • Optional methods: A) Mounting with hose and plug B) Concealed wiring mounting (recommended) •...
- Page 3 - Not to force the connector's connexion. - By handling it later recall not to pull the sensor's wire between the base and the cover. WIRING DIAGRAM BREAKDOWN LIST OF BASIC PARTS Mediclinics’ Description Reference number part number Motor RC95748-UL Heating...
- Page 4 METHOD OF USE To dry correctly is recommended rising well to remove all traces of soap. Button models: Press the start button. Immediately after approach the hands to the air outlet and rub them together. The hands can be gradually taken away from the dryer and will continue drying up to a maximum distance of 10-15 cm (4"...
- Page 5 8- Start up the machine and leave until no further dust remaining from the cleaning process, comes out from the nozzle. CLEANING OF CHROMED AND GOLD PLATED COVERS For cleaning purposes only a wet cloth is to be used. Do not use any kind of detergent, acids, lye, abrasives, hydrochloric acid, etc.
- Page 6 MODEL MODÈLE MODELO E85-UL E85A- E88-UL E88C- E88CS- E88A- E888AC- E88ACS- GENERAL: GÉNÉRAL : GENERAL: 110 – 120 VAC Input voltage: Alimentation : Alimentación: 50/60 Hz Consumption: Consommation : Consumo: 16 A Puissance Potencia Rated power: 2.5 Hp (1,850 W) nominale : nominal: Weight:...
- Page 7 ANNEX MOUNTING INSTRUCTIONS. To mount onto wall, be sure there are no hidden electrical circuits or pipes in the mounting location. Place the mounting template (provided) on the wall to mark location of four mounting screw holes. Drill four holes (Fig.1) Ø8 (5/16”) diameter and 45mm (1 ¾”) depth. Take off the residual dust from the holes.
