  • Page 1 SECADOR DE MANOS / HAND DRYERS / SÉCHE-MAINS / HÄNDETROCKNER / SECADOR DE MÃOS / ASCIUGAMANI / СУШИЛКА ДЛЯ РУК / ΣΤΕΓΝΩΤΗΡΑΣ ΧΕΡΙΩΝ / ‫ف اﻟﯾدﯾن‬ ‫ﺟﮭﺎز ﺗﺟﻔﯾ‬ M99A / M99AC / M99ACS / M88PLUS / M88APLUS MANUAL DE INSTALACIÓN Y UTILIZACIÓN INSTALLATION AND OPERATING MANUAL MANUEL D’INSTALLATION ET D’UTILISATION...
  • Page 2: Safety Instructions

    RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by www.mediclinics.com ENGLISH SAFETY INSTRUCTIONS Before to carry on any operation, please read carefully and take into account the following safety instructions: - Only a qualified technician can install, adjust and maintain this device. All this operations must be always done according to the current legal European Standards of installation and according the local installation regulations as well.
  • Page 3: Installation

    RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by INSTALLATION Dismantling for installation • The dryer is supplied with a pressure-mounted cover, and is not screwed down. • The 4 attachment screws are provided in the plastic bag with the plugs and lag bolts. •...
  • Page 4: Wiring Diagram

    RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by www.mediclinics.com WIRING DIAGRAM Automatic models H - Heating element M - Motor S - Sensor Models with pushbutton H - Heating element M - Motor T -Timer ADJUST DETECTING DISTANCE The hand dryer has means to adjust manually the distance for detecting hands.
  • Page 5: Method Of Use

    RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by BREAKDOWN LIST OF BASIC PARTS COMPONENT NUMBER CODE White plastic pushbutton cover RC92200 PLUS White automatic cover RC92830 SS Chrome bright automatic cover RC92830 SS Chrome satin automatic cover RC92832 SS White plastic automatic cover RC92204 PLUS Scroll-fan...
  • Page 6: Preventive Maintenance And Cleaning

    704 . 937. 2673 www.RestroomDirect.com distributed by www.mediclinics.com This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 7 RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by www.mediclinics.com MODELO MODEL MODÈLE MODELL M99A M99AC M99ACS M88A PLUS PLUS GENERAL: GENERAL: GÉNÉRAL : ALLGEMEIN: Stromversor- Alimentación: Power supply: Alimentation : 220 – 240 V 50-60Hz. gung: Power Consommation...
  • Page 8 RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by ELIMINACIÓN DE RESIDUOS DE APARATOS ELÉCTRICOS Y ELECTRÓNICOS POR PARTE DE USUARIOS DOMÉSTICOS EN LA UNIÓN EUROPEA. El producto que ha adquirido ha sido diseñado y fabricado con materiales y componentes de alta calidad que pueden ser reciclados y reutilizados. Cuando vea un producto marcado con este símbolo de un contenedor de basura con ruedas tachado significa que dicho producto está...
  • Page 9 RESTROOM DIREC T 704 . 937. 2673 www.RestroomDirect.com distributed by MEDICLINICS, S.A. Industria, 54 E-08025 BARCELONA SPAIN Tel.: +34 934 464 700 Fax: +34 933 481 039 info@mediclinics.com 12/11/13 COD.: 92615 www.mediclinics.com...
