MecArmy PT60 User Manual

Primary Features:

·Uses 16 CREE XP-G2 S4 LEDs, Max output up to 9600 lumens
· Micro USB Intelligent charging inputs; compatible with any USB port
· 3 available Micro USB charging ports, allows quick charge in 3 hours
· DC 5V/ 2A USB output, can be used as a power bank
· Accurate battery capacity indicators
· Charging and fully charged indicators
· Max 58WH battery cell capacity, built-in capacity up to 13600mAh
· 18650 li-ion battery pack, max running time up to 26 days for PT80
· Max beam distance 415 meters
· Portable handle available as an accessory
· Pure copper and gold plating circuit boards
· Integration and high efficiency optical lens
· Four independent constant current drivers
· Built-in temperature testing system, keeps the temperature at 45 degrees
· Aggressive head bezel for self defense
· High efficient heat dissipation design
· Rugged pineapple texture for better grip; anti-roll
· Tail stand capability
· Gun mount available as an accessory
· Standard 1/4 inch Tripod mount4
· Constructed from aero grade aluminum alloy, with HAIII hard-anodization
· IPX-8 water resistance

PT60 Specification

LED: 16 CREE XP-G2 S4 LEDs
Output & Runtime
ANSI/NEMA FL 1
Output(Lumens)
Running time(Hour)
Peak beam intensity (cd)
Max beam distance(m)
Impact resistance(m)
Waterproof

Dimensions

Length: 124mm/ 4.88in
Head diameter: 75mm/ 2.95in
Body diameter: 52mm/ 2.05in
· Weight: 450g/ 15.87oz (excluding battery pack)
PT60 User Manual
Patented Ultra Bright USB Rechargeable Flashlight
Turbo High
9600 2120
2.28 2.83
Middle Low
500 21
16.17 331
43238
415
1.5
IPX8 (under water 2meters)
Strobe SOS
9600 9600
/ /
