MecArmy FM11 User Manual

Patented USB rechargeable Multifunctional Flashlight
Features：
Durable stainless steel body
•
CREE XP-G2 S4 LED, max output 130 lumens
•
Rechargeable 10180 li-ion battery (included)
•
•
Charging and fully charged indicator
•
Standard Micro USB charging port, chargers in just 1 hour from any USB source
3 mode design, Med/Moonlight/High
•
•
Specially designed switch gives easy one-handed operation, and prevents
•
Easy to access to different lighting functions
accidental activation
•
Magnetic tailcap provides versatile hands free operation
Headband allows use as headlamp
•
Detachable clip
•
IPX-8 waterproof
•
•
Emitter: CREE XP-G2
Specification：
Output & Runtime
ANSI/NEMA FL 1
Output (lm)
Runtime
Peak beam intensity(cd)
Max beam distance(m)
Impact resistance(m)
Waterproof
Length:56.5mm/2.22in
Head diameter: 16.9mm/0.67in
•
Body diameter：13.2mm/0.52in
Weight: 32.9g/1.16oz (excluding battery)
Battery:10180 100mAh Li-ion battery
•
Working voltage: 3.2V-4.2V
Accessories: Manual, lanyard, clip, 2*O-rings and headband
•
•
NOTICE: The above-mentioned parameters are approximate and may vary
between flashlights, batteries and environments.
FM11 User Manual
High
30mins
130
IPX8（underwater 2 meters）
Med
3.4h
14
431
34
1.5
Low
15hours
0.2
