MecArmy CPL3 Quick Start Manual

MecArmy
CPL3 USB-C Knife Back Clip Attachable
LED Mini-Light
Primary Features
· USB Type-C Knife clip LED Flashlight
· Utilizes CREE XP-G2 S4 LED, max output 300 lumens
· Max beam distance of 31 meters
· Uses rechargeable 55mAh lithium polymer battery
· USB Type-C charging port, charges in just 1 hour
· Charging and fully charged indicators
· Four lighting modes and Strobe function
· 1.5*6mm glow bar slots available on the clip
· Unique switch prevents accidental activation
· General 3 screw knife/multitool back clip compatible
Dimensions
Length: 32mm /1.26"
Width: 27mm /1.06''
Thickness: 12mm /0.47''
Titanium Weight: 28g /0.988oz
Aluminium alloy Weight: 23g /0.811oz
Battery: Rechargeable 55mAh lithium polymer battery
Charging time: 1 hours (charging current 5V /0.8A)
Working voltage: 3V-6V
Accessory: User manual, USB cable
Specifications
LED: CREE XP-G2 S4
Mode/ Specification Turbo
300
Output (Lumens)
55
Runtime *2+38mins
Peak beam intensity
Max beam distance
Impact resistance
Waterproof
NOTICE: The above mentioned parameters are approximate and may
vary between flashlights, batteries and environment.
Operation
1. From OFF: Double click (Low mode)
2. From ON: Click to cycle through low-med-high
3. From ON: Long press at any mode to turn OFF
4. From any mode: Triple click to access Turbo; another click from Turbo
for Strobe, click again for OFF.
High Med Low Strobe
110 16 4 300
55
*2+45mins 1.6h 7.1h
95cd
22m
1m
IPX6
Charging
Carefully remove the cap from the USB charge port, and connect the
supplied USB charging cable, as shown in the diagram below:
Charging Indicator
When charging, the light will turns red, when charging is complete, the
light turns green
No light indicates that there is no load
Warning
a. Do not look directly into the emitter when it's turned on
b. Do not point the light at human or animal eyes
c. Do not permit children to use the light unsupervised
Warranty
a. Guaranteed exchanged up to 15 days after purchase: Any defective
product can be exchanged for a replacement through a local
distributor/dealer within 15 days.
b. After 15 days: All defective products can be repaired free of charge for
a period of 2 years from the date of purchase.
c. Lifetime workmanship guarantee: After the free maintenance period
has expired, the maintenance service will charge for material
expenses only, free of labor expenses.
ALTUN LIMITED
TEL: +86-755-23764109
FAX: +86-755-23760255
Email: info@mecarmy.com
Address: Yikang Mansion, Huarong Road,
Dalang Street, Longhua District,
Shenzhen, China
www.MecArmy.com
USB-C
