MecArmy SPX18 User Manual

MecArmy's new Tactical high performance flashlight

Primary Features

•
Patented innovation tactical flashlight, with a new concept in switches that can
be operated through 360 degrees in any angle
•
Instant access to STROBE from ON/ OFF
•
Uses CREE XM-L2 U3 LED, max output up to 1100 lumens
•
FREE USB rechargeable 3400mAh 18650 battery, with Panasonic cell and built in
Micro USB connector
•
Momentary ON function, one-handed operation
• Charging and fully charged indicators for USB rechargeable battery
•
Standard Micro USB Charging port, charges on any USB port
•
Standard 1 inch body design, suitable for common gun mount
•
3 mode design, easily changed by 360 degree push High/Low/Med
•
Specially designed tail and head for shock and impact resistance
•
Detachable tactical ring and clip
•
Aggressive bezel on the head for self defense
Compatible with any 18650 or 2x16340、2xCR123A battery
•
Optional four colors filters
•
•
Anti-roll and antiskid body design
• Reverse polarity protection prevents damage from an incorrectly inserted
battery
•
Constructed from aero grade aluminum alloy, with HAIII hard-anodization
• IPX-8 water resistance

Specification

Emitter: CREE XM-L2 U3 LED
Output& Runtime
Mode/ Specification
Output (Lumens)
Runtime (h)
Peak beam intensity (cd)
Max beam distance (m)
Impact resistance (m)
Waterproof
•

Dimensions

Length：147.5mm/ 5.81in
Head dimension：35.0mm/1.38in
SPX18 User Manual
High
1100
2.28h
Med Low
306 27
5.33h 125h
20660
287
1.5
IPX-8 (underwater 2 meters)
Strobe
1100
