- Page 1 PTZ Camera Dante AV ™ Decoder Quick Start Guide Version 1.0...
-
Page 2: Optional Accessories
This quick start guide applies to D412, D220, D10H Items included in the camera box VCC-CC45RS RJ45 to RS232 Control cable x 1 VCC-RC-2 D412/D220 VCC-P12-4 VCC-CC45RS Power Cord x 3 IR Controller x 1 Power Adaptor x 1 Dante AV Camera x 1 RJ45 to RS422 Control cable x 1 (Type: US, EU, UK) Batteries not included）... -
Page 3: Connection Diagram
Camera HDMI Output Setup 1. Item List Supports HDMI 2.0 Display Output Device x1 (Not included) HDMI 2.0 Cable x1 (Not included) 2. Connection Diagram Dante AV PTZ Camera HDMI IN 1 2 3 4 5 6 7 8 HDMI 2.0 Cable Connection DC 12V 4A Display Output Device 3. - Page 4 5. Dante AV Camera Startup HDMI IN Wait after the camera finishes turning, tilting and scanning its range. POWER HDMI 2.0 Cable Connection The Power indicator stays solid green when POWER STATUS the camera is powered on. Once the on screen display (OSD) menu disappears, the camera is ready for use.
- Page 5 3. Connection Diagram Dante AV PTZ Camera Direct Camera HDMI Output 1 2 3 4 5 6 7 8 Display Output Device Network Cable Connection (POE Powered) Two Ethernet ports available, only Port 1 supports POE++. Dante Controller Dante AV Decoder POE++ Switch Display Output Device Note: ①.
- Page 6 5. Dante AV Decoder Startup Dante AV Decoder Green: Normal Green: Normal, Not lit: Abnormal/Error Switch on the decoder after connecting the power Green: Normal, Yellow: Starting up, Red: Abnormal/Error Green (Blinking): Normal, Red: Abnormal/Error Green: Dante network clock slave, sync achieved Green (Blinking): in sync with leader clock,Red: Abnormal/Error Green: Not protected, Green (Blinking): Protected,Red: Abnormal/Error For Dante AV camera startup tips, please refer to its respective diagram.
- Page 7 Dante Controller Video - Network View File Devices View Help P r i m a r y L e a d e r C l o c k : D 2 2 0 - 0 2 2 5 a 2 Routing Events Device Info Clock Status Network Status...
- Page 8 7. Camera Remote Control Setup ① Connection Diagram Group A PTZ Keyboard RS422 VISCA Port Controller (Optional) Cat6 Network Cable Dante AV Cat 6 Network Cable, Powered PTZ Camera Front Side Back Side Dante AV Decoder Cat6 Network Cable,POE Powered Cat6 Network Cable,POE Powered ②...
- Page 9 2082 TECHNOLOGY LLC dba BOLIN TECHNOLOGY...
