Bolin Technology Dante AV D20H Quick Start Manual

Encoder / decoder

Advertisement

Quick Links

Dante AV
Encoder / Decoder
Quick Start Guide
Version 2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dante AV D20H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Bolin Technology Dante AV D20H

  • Page 1 ™ Dante AV Encoder / Decoder Quick Start Guide Version 2.0...
  • Page 2: Optional Accessories

    This quick start guide applies to D20H, D20S Items included in the encoder / decoder box VCC-CC45RS D20H/D20S Power Cord x 3 RJ45 to RS422 Dante AV Encoder/Decoder Power Adaptor x 1 (Type: US, EU, UK) Base Mount Kit x1 Control cable x 1 M4*6PW Screw x 8 M2.5*3C Screw x 8...
  • Page 3 3. Connection Diagram 12G-SDI Display Output Device HDMI Display Output Device Only D20S Support12G-SDI Output 12G-SDI Cable x1(Not Included) USB2.0 RS-232 RS-422 IR Select Audio Video FW Upgrade Only Format 1 2 3 DC-12V HDMI MicroSD 6G/3G-SDI Genlock LAN/PoE HDBaseT PTZ Camera HDMI Output Dante AV Encoder...
  • Page 4 5. Dante AV Decoder Startup Dante AV Decoder Green: Normal Green: Normal, Not lit: Abnormal/Error Switch on the decoder after connecting the power Green: Normal, Yellow: Starting up, Red: Abnormal/Error Green (Blinking): Normal, Red: Abnormal/Error Green: Dante network clock slave, sync achieved Green (Blinking): in sync with leader clock,Red: Abnormal/Error Green: Not protected, Green (Blinking): Protected,Red: Abnormal/Error Note:...
  • Page 5 Dante Controller Video - Network View File Devices View Help P r i m a r y L e a d e r C l o c k : D 2 0 S - R X- 0 2 2 5 a 2 Routing Device Info Clock Status...
  • Page 6 7. Camera Remote Control Setup ① Connection Diagram Group A PTZ Keyboard Controller USB2.0 RS-232 RS-422 IR Select Audio Video FW Upgrade Only Format 1 2 3 (Optional) DC-12V HDMI MicroSD 6G/3G-SDI Genlock LAN/PoE HDBaseT Cat 6 Network Cable, PTZ Camera RS422 VISCA Port POE++ Powered Cat6 Network Cable...
  • Page 7 ③ Subscribe RS-422 Channel on Dante Controller Dante Controller Video - Network View File Devices View Help P r i m a r y L e a d e r C l o c k : D 2 0 S - R X- 0 2 2 5 a 2 Routing Device Info Clock Status...
  • Page 8 2082 TECHNOLOGY LLC dba BOLIN TECHNOLOGY...

This manual is also suitable for:

Dante avd20s
