JBL Control Control 26CT Technical Manual

Technical Manual
JBL CONTROL 26CT

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal Impedance:
• Power Capacity:
• Frequency Range:
• Sensitivity:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet:
• Grille:
• Woofer, Tweeter
Transducer:
• DC Resistance:
• Taps
PACKAGE
Ceiling Rails (4)
888-00062-00
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
16 ohms
140W Continuous Program
75 Hz to 20 kHz
89 dB, 1 Watt @ 1 Meter
4 kHz
389-00029-01
152mm (6in.)
124-16000-00
12.8 ohms
60W, 30W, 15W and 7.5W at 70V
60W, 30W, and 15W at 100V
Warranty 59660
Owners Manual
CEILING SPKRMAN
C-Bracket (2)
888-00061-02
SYSTEM COMPONENTS:
• Crossover Network:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

Woofer, Tweeter
124-16000-00
BLK
RED
SCHEMATIC 129-20048-00
SW
RED
ORG
VIO
INPUT
BLU
WHT
BLK
*
NOTE:
All Models with Line Transformers are Tested at the Lowest Power Position
(3.7W/70V for the 24CT, and 7.5W/70V for Both the 26CT and 19CST Models),
with a Reversed Transformer in the Same Power Position Between the
Speaker and the Amplifier.
(cont'd)
129-20048-00
*
12.0V Input, 75 Hz to 20 kHz
210mm x 252mm Dia.
(8.3 x 9.9 in. Dia.)
24 lbs. (10.88 kg.) (in Pairs)
Network
129-20048-00
BLK
WHT
RED
YEL
PCT
T1
RXE065
562-00036-00
BLK
GRN
WHT
C1
2.0µF
L1
0.445mH
Woofer
Tweeter
BLK
05-03
