- Page 1 JBL ON AIR ™ Control 2.4G Powered Loudspeaker SERVICE MANUAL JBL Consumer Products 250 Crossways Park Dr. Woodbury, New York 11797 Rev0 5/2007...
- Page 2 On Air™ Control 2.4G Service Note: Defective Control 2.4G systems should be exchanged under the warranty period; the electronics are not serviceable down to component level Order the following parts when needed: Mechanical parts see pages 8,9,10 Powered Loudspeaker part# CONTROL 2.4G-L Passive Loudspeaker part#...
- Page 3 Technical Manual On Air ™ Control 2.4G CONTROL 2.4G PACKAGING ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY. Warranty Card 12 376-000-01092-E Wall-mount Holder For Transmitter 2 406-000-05568-E Owner’s Manual 13 188-0506401-E Control 2.4G Remote Control 3 152-V65301A05-E 230v AC Plug/Cord for AC Adapter (6.5ft) 14 CONTROL2.4GLAUNCHE Control 2.4G Transmitter (complete)
- Page 4 On Air™ Control 2.4G...
- Page 5 Subwoofer The JBL On Air Control 2.4G is designed for use in most countries worldwide, depending upon local regulations. It includes 120V – 230V, 50/60Hz universal power supplies for the transmitter module and the active speaker. While we...
- Page 6 Use this polarity stripe to ensure connect the computer to the JBL On Air Control 2.4G using preamp outputs on that you are connecting the positive (+) terminal on one speaker to the positive your computer, follow the steps in Connection A.
- Page 7 On Air™ Control 2.4G When connected properly, the top LED on the front of the active speaker Step 4. should be green. When first plugged in, it will sometimes take several seconds Plug the transmitter module B and active speaker 6 into the wall outlet, for the Control 2.4G active speaker to initialize and “wake up.”...
- Page 8 From this point on, you will use the remote control included with the JBL On Air Control * One mini-jack – dual RCA cable is included with the system. If you are following 2.4G wireless speaker system to adjust the volume 1 and 2.
- Page 9 Technical Manual On Air ™ Control 2.4G CONTROL 2.4G POWERED LOUDSPEAKER ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY. 242-050-05221-0BAE Front Grille 352-AM03512D278-E Screw For AMP PCB 352-GM04035D809-E Screw, Baffle (3mm hex key) 011-7603-05064-E Amplifier/receiver module PCB 243-050-05153-0BAE Front Baffle Not for Sale...
- Page 10 Technical Manual On Air ™ Control 2.4G CONTROL 2.4G PASSIVE LOUDSPEAKER ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY. 242-050-05221-0BAE Front Grille 352-BM03010D974-E Screw, Terminal Cup 352-GM04035D809-E Screw, Baffle (3mm hex key) 317-ABS-05078-0BAE Terminal Cup 243-050-05158-0BAE Front Baffle Not for Sale Enclosure cover (Top)
- Page 11 Technical Manual On Air ™ Control 2.4G CONTROL 2.4G TRANSMITTER ITEM NO. PART NO. DESCRIPTION QTY. ITEM NO. PART NO. DESCRIPTION QTY. 303-ABS-05099-0BAE Top Cover 236-050-05017-0BAE Holder, Antenna 351-AM03005A015-E Screw For Transmitter PCB 352-AM02606C1136-E Screw, Antenna Holder CONTROL2.4GLAUNCHE PCB not available, only entire 304-SPCC-050860BAE Bottom Enclosure Transmitter stocked...
- Page 12 On Air™ Control 2.4G...
- Page 13 2) Locate the four resistors R38,41,46 & 67 on the main PCB. (See illustrations) • Change R38, R41 from 9.1K to 3.3K SMD 603 size, JBL part# P3.3KGCT-ND • Change R46 from 510K to 2.2M SMD 603 size, JBL part# P2.2MGCT-ND •...
