two.

Speaker Connections

Connection Tips

CM40, CM42, CM40AW, CM42AW
LEFT
+
–
– +
LEFT
Front or Rear Speaker Outputs
CM52, CM62, CM52AW
RIGHT
– +
Speakers and electronics ter-
minals have corresponding
(+) and (–) terminals. It is
important to connect both
speakers identically: (+) on
the speaker to (+) on the
– +
RIGHT
– + – +
RIGHT LEFT
Front or Rear Speaker Outputs
RIGHT
+
–
LEFT
– +
amplifier and (–) on the
speaker to (–) on the ampli-
fier. Wiring "out of phase"
results in thin sound, weak
bass and a poor stereo
image.
CM Center
– +
– +
Center Speaker
Output
