Summary of Contents for VIVID STORM S PRO
- Page 1 SPROElectricTab-TensionFloorScreen Donottouch thescreenmaterial...
-
Page 3: Table Of Contents
Content TheIntroductionofProduct ------------ 2 S c r e e n R u n n i n g - - - - - - - - - - - - - - - - - - - - - - - - - - - 1 6 Appearance ------------------------------- 2 Manual Switch ----------------------------- 17 Accessories List ------------------------- 3... -
Page 4: TheIntroductionOfProduct
TheIntroductionofProduct Appearance Upper cover Screen material Screen Black border Housing IR receiver Power cord socket Power Switch Screen manual switch Schematic diagram of left end cover Donottouch thescreenmaterial... -
Page 5: Accessories List
Accessories list Power cord Adjust Rod Small Bracket Screw remote control remote control (Hard and soft) x4 pcs Gifts Thetwopartsontheleftare freegifts,sotheyarenotcovered bythewarranty. Special cleaning brush Cleaning stickers for screen material... -
Page 6: ImportantSafetyPrecautions
ImportantSafetyPrecautions Pleasereadallthecontentsoftheuserguidecarefully andfollowtheoperationstepsbelow. For reference when necessary, please keep this user guide. 1. In order to avoid damage to the equipment, please prohibit the use of any accessories not authorized by the manufacturer. 2. Be sure to handle the products carefully during transportation, so as to prevent product damage caused by collision. -
Page 7: MattersNeedingAttention
MattersNeedingAttention Warning! If you do not strictly follow the prescribed precautions during use, this may lead to equipmentdamageandotherunnecessarydamage. Pleaseobservethefamilyfiresafetyregulations;donotplacetheequipmentnearthefireplaceor hightemperatureobjectssuchasgasstove,barbecueorheatertoavoidequipmentdamage. Pleasekeepthisproductoutofthereachofchildren. Pleasedonotputanysundriesinsideofthecovertoavoiddamagetotheequipment. The seller and the manufacturer are not responsible for any damage to the equipment caused thereby. Beforethescreenturnsoff,pleasemakesurethereisnodebrisinthecover. - Page 8 Do not place the equipment near the fireplace or high Do not put your hands into temperature objects such as thecoveroftheproduct gasstove,barbecueorheater Do not put any sundries insideofthecover; Keepchildrenawayfrom Beforethescreenturnsoff, theproduct please make sure there is nodebrisinthecover Movingparts! Keepbodypartsawayfrom movingparts.
-
Page 9: Precautions For Use
Precautions for Use No one is allowed to open the inside of the equipment and repair the product without authorization, except for the authorized technicians. 1. Please make sure that the power supply connected to this product has stable current. 2. -
Page 10: MattersConcerningProjection
MattersConcerningProjection Projected Area 1.Please project according to the actual projection size of the screen purchased when using the projector. 2.Since the position of black border has been preset on the screen of this product, please do not exceed the specified projected area during projection. You should note that the default black border is not the projection area. -
Page 11: Screen And Projector Compatibility
Screen and projector compatibility Please note that the screen of this product is only suitable for use with Ultra short throw laser projector. If it is used with other projector ，the effect of picture will be greatly reduced. Ambient light can be absorbed It is suggested that the ultra short focus laser projector throw ratio... -
Page 12: AboutScreenPerformance
AboutScreenPerformance 1.Please note that when placing this product, please make sure that the product is always in a horizontal state. Do not place the screen in an inclined or vertical position. 2. After using for a period of time, if the cover on both ends of the screen is slightly tilted, there is no need to worry. This is a normal phenomenon and does not affect the viewing and use. - Page 13 4.When there are a few black spots, white spots, stains and other impurities on the screen surface, but if they are qualified according to the detection method, then such situation is not a product quality problem, and it is within the scope of product qualification. The ambient illumination of the central point is 500-600lx 45°...
- Page 14 For the black spot defect which can be F o r t h e a p p e a r a n c e o f s p e c i fi c measured in appearance, if it can not be measurable white spot defects, if visual found by visual inspection, the product is inspection can not be found, then the...
-
Page 15: InstallationWarning
InstallationWarning Since the installation environment of each user is different, the instructions in this user guide are only for reference. If you need further installation and safety suggestions, please consult the professional installation company. It should be noted that no matter what kind of installation method you take, the product should not be loosened or dropped due to vibration or tension, so as to keep the product stable. -
Page 16: GroundInstallation
GroundInstallation Safety tips: it is recommended that two people lift the product and place it horizontally. 1. When using this product, you can place the product on the horizontal ground and fix it. Before placing the product, please pay attention to cleaning the ground debris to keep the floor dry. 2. -
Page 17: WallInstallation
WallInstallation (The wall hanger can be used as a reference If additional purchase it) 1. If you purchase the wall bracket, you can fix the product screen on the wall. 2. When installing the product, first you need to make a horizontal mark on the wall and mark the hole position, and then fix the wall bracket on the wall. -
Page 18: S C R E E N R U N N I N
ScreenRunning Voltage information: make sure your screen is working at the correct voltage , depending on the area. (Using the wrong voltage may cause the screen to become inoperable) (1) Plug the screen power cord into the correct power outlet. (2) When the product power is turned on, a "beep"... -
Page 19: Manual Switch
1.Manual Switch The left side of the screen shell is equipped with a manual switch which can control the screen "up / stop / down". Stop Down Position of manual switch... -
Page 20: Remote Control
2.Remote control——RF remote control / IR remote control (1) Wireless RF remote control: when the screen is hidden and installed in the slot or requires remote control, wireless remote control can be used. It can control the screen without aiming at the IR receiver. (2) IR remote control needs to be connected with the IR receiver. - Page 21 For convenient access, the remote controller can be fixed on the wall surface and other planes through the bracket.(wall screw or double-sided adhesive tape can be used for fixation)
- Page 22 When the battery of the remote control needs to be replaced, as shown in the figure below, unscrew the cover of the remote control with a small screw, then replace the new button battery, close the cover of the remote control, and tighten the screw to prevent the loose battery from falling off;...
-
Page 23: ScreenHightLimitSetting
Screenhightlimitsetting Black border down （The highest position of the screen has been set when leaving the factory, no higher height can be adjusted） If the screen is too high, follow the steps below to fix the screen to the desired position. 1. - Page 24 Open the rubber plug Open the rubber plug under Insert the adjusting rod into the Yellow hole in Yellow hole position the left side of the cover the housing and rotate clockwise (rotate one circle and adjust the screen height about 2cm) Then press the "up"...
-
Page 25: Black Border Up
Black border up （Only applicable after the black border is adjusted too low） If the height adjustment of the black border of the screen is too low, please follow the following steps: (please note: it is not allowed to carry out this step directly without adjusting too low) (1) Please press the "up"... - Page 26 Open the rubber plug Open the rubber plug under Insert the adjusting rod into the Yellow hole in the Yellow hole position the left side of the cover housing and Counter clockwise rotation (rotate one circle and adjust the screen height about 2cm) Onlyapplicableaftertheblackborderis adjustedtoolow ！...
-
Page 27: S C R E E N M A I N Te N A N
Screenmaintenance Cleaning requirements: 1. In general, please use a soft brush to clean the screen surface. Remember to use a special soft brush and gently brush away the impurities along the screen grain direction. 2. Do not use any cloth (coarse cloth, soft cloth, gauze, wet cloth) to wipe the screen surface. 3. -
Page 28: M A N U Fa Ct U Re R 'S Wa R Ra N T
Manufacturer'swarranty 1.VIVIDSTORM products have a 2-year warranty. During the warranty period, in case of any problems caused by the product itself or the product defects caused by the design, Please contact the after-sales service to inform the situation. During the warranty period, if the product fails to work normally due to user negligence (not product material or design defects, etc.), not eligible for a warranty, for serious damage to the product should charge that fee according to the product damage. -
Page 29: ProductWarrantyCard
Official website of the company：http：//www.vividstormscreens.com Consultation email：vividstormscreen@gmail.com...
