- Page 1 Smart Wall Plug (USA Type) WL-ZSKMNPW-M3140-01 WL-ZSKMNPW-M3141-01 User Manual...
- Page 3 Features ●Support IEEE 802.15.4 ZigBee/SmartRoom protocol. ●Power has the overload protection function. Can monitor the present power & electric quantity in real time. It saves energy and keeps away from stand-by power consumption (This function is for metering type). ●Remotely control connecting to power, or shutting down power for home appliances by smart home APP. Auto-timing control function of energy saving makes common appliances smart.
-
Page 4: Product Parameter
Product Parameter IEEE 802.15.4 Material & Color PC+ABS、White Communication Protocol （ZigBee/SmartRoom） Flame Retardant Rating UL94 V-0 Antenna Type PCB Antenna Net Weight (g) Power Parameter 120-125VAC， 60Hz Weight (g) Maximum Rated Current Operating Temperature -10℃～+45℃ Standby Power Consumption ≤0.3W Overall Dimension ≤95%RH Operating Humidity 123×57.2×62.3... -
Page 5: Package List
Package List Guarantee Manual Card Smart Wall Plug (USA Type)*1 Manual *1 Guarantee Card*1... - Page 6 Function / Installation Illustration ON/OFF Key Wall Multi-Functional Key System Indicator Main Body of Socket Appliance Plug Plughole...
-
Page 7: Network Setting
Network Setting 1.Add ZigBee Network for the First Time [System Indicator] Search network flashes in green Apply for joining ZigBee network Quickly click [Multi-Functional Key] 4 times（Each click is less than 1s） [System Indicator] is on 2s, and then Join ZigBee network goes out successfully Notes:... - Page 8 2.Binding Long press [Multi-Functional Key] while click [ON/OFF Key] once quickly. Then loosen [Multi-Functional Key]. Binding succeeds [System Indicator] flashes Binding finishes green 3 times. [System Indicator] flashes once to send binding request. Bind device that requires binding within 20S with same steps. [System Indicator] flashes green 6 times quickly.
- Page 9 3.Exit ZigBee Network and Restore to Factory Setting Restore to factory setting [System Indicator] flashes green 4 times, and then goes out. Long press [Multi-Functional Key] 10S. Exit ZigBee network Notes: The default factory setting does not join ZigBee network.
- Page 10 User Guide 1.Press [ON/OFF Key], and this product is connected to power, then [System Indicator] stays blue. Press [ON/OFF Key] again, and shut down power, then [System Indicator] goes out. 2. User can check real-time power and used electricity of appliances at work by smart mobile terminals to save more energy.
-
Page 11: Installation Cautions
Installation Cautions ●Please keep this product far away from the area that have interference source like washing machine, microwave oven, refrigerator and router, or it will affect sensitivity and working performance of the product. ●This product should be installed in dry and clean place to prevent inner component from dampness or other debris.
