- Page 1 Wireless Mobile Smart Socket (European Standard, F type) WL-ZSKMNPW-M3131-02 WL-ZSKMNPW-M3130-02 User Manual 2015Nanjing IOT Sensor Technology Co.,Ltd Publication No.: 2015-0318.V01...
- Page 2 ●Before installing and using the products, please read user manual carefully, which will help you use the products better. ●Wulian wireless Mobile Smart Socket(for short “this product”)is made by Nanjing IOT Sensor Technology Co., Ltd(for short “our company”).This product should be used together with app and its accessories.
- Page 3 Product display, installation effect ON/OFF Key Multi-functional Key Wall System indicator light Socket Body Plug Plughole...
-
Page 4: Function Features
Function Features ●The world’s leading technology power overload protection, support to monitor the real-time current and power consumption.Save Energy at your will,and avoid the standby power waste. (measurement vision only). ●Turn the traditional appliances into smart appliances through remotely turn on/off, eco-friendly timing by APP. -
Page 5: Software Download
Users can scan QR code on package to download the newest app. Method Two: Users can also directly download from our official website: http://www.wulian.cc/service.shtml Warm Notice: please install the APP firstly, and read the product instruction manual carefully ; Please always pay attention to our information, in order to... - Page 6 1.Network setting. Apply to join the zigbee network Search for network 【system indicator light】 turns green and flashes Quick press [multi-functional key] 4 times 【system indicator light】turns (Do not longer than 1 second for green and long flashes 2 each press Sucessful joined seconds and then turns off.
- Page 7 2.Binding Press the【Multi-functional key】， and quick press【ON/OFF】once， then move your finger way from 【multi-functional key】 Finish Sucessfully operated for 【system indicator binding binding light】turns green and 【system indicator light】flashes once flashes 3 times. and send out the message about bindin，Please operate the same way as [multifunctional key] in 20S 【system indicator light】turns green and...
- Page 8 3. Logout and Restore factory default setting system indicator light 【 】 turns green and flashes Restore factory 4 times then turn off. Long press default setting multi-functional key 【 】 10seconds Logout ZigBee network Notice: Restore factory default setting defaults to out of zigbee network.
-
Page 9: Operating Guidance
Operating Guidance 1.Press【ON/OFF】，the socket will be power-on,【system indicator light 】will stay blue;Press[ON\OFF】again,the socket will be power-off and 【system indicator light 】will be off. 2. Customers can check the current and power consumption of the electric appliances via the mobile terminals, and it can save energy. When the load is over 3000W, it can cut the power automatically to protect the electric appliance.(metering version only). - Page 10 Cautions ●Please put the product far away from the interference sources of washing machine, microwave oven, refrigerator, routers etc..Or it will probably affect the product communica- tion sensitivity and its working performance. ●The product should be installed in a dry clean place, avoid internal components to be affected with damp or other impurities into to affect the using effect.
-
Page 11: Product Specification
Product Specification Communication Mode IEEE 802.15.4 ZigBee/SmartRoom ANTTYP PCBANT Power Demand 230-250V AC，50/60Hz Rated Max. current Outside Size (L*W*H,mm) 123*57.2*78.6 Max. Resistive Load 2500W (incandescents,halogen etc.) Max.Inductive,capacitive load 1500W (CFL,Fluorescent,LED etc.) Materials, Color PC+ABS、White Flame Retardant Rating UL94 V-0 N.G (g) Working Temperature -10℃～+45℃... -
Page 12: Order Information
Order Information Wireless Mobile SmartSocket Product Wireless Mobile Smart Socket (European Standard, F type), Description (European Standard, F type) Metering Type WL-ZSKMNPW-M3131-02 Model WL-ZSKMNPW-M3130-02 PC+ABS，white Materials,Color PC+ABS，white WLPN150320001 Item NO. WLPN150320002... - Page 13 Building 11, No.15, Fengji Road, Yuhuatai District, Nanjing (P. C.: 210039) Email: overseas@wuliangroup.com Service Hotline：400-889-2891 www.wulian.cc...
