- Page 1 Smart Contact Sensor FOR WL-ZSPDBPW-MT-01 User Manual ©Nanjing IOT Sensor Technology Co., Ltd. Publication Number: 2015-0407.V01...
- Page 2 Federal Communications Commission (FCC) Compliance Notice: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 Federal Communications Commission (FCC) Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
-
Page 4: User Manual
Sensor Technology Co., Ltd. (hereinafter referred to as “Wulian”). This product shall be used with smart home APP as well as the supplied accessories. Wulian is not responsible for any loss due to improper installation and usage of this product. - Page 5 Features ●Support IEEE 802.15.4 ZigBee/SmartRoom protocol. ●Under defense, remotely control door is open or closed, and send real-time monitor status to smart APP. ●Make scene setting by smart APP for linkage with our other devices. ●Alarm with wireless transmission brings about rapid response, high anti-interference, and low rate of false alarm.
-
Page 6: Product Parameter
Product Parameter IEEE 802.15.4 Communication Protocol （ZigBee/SmartRoom） Antenna Type PCB Antenna Power Parameter DC 3V Battery Type CR2*1 Stand-by Current 2uA at opening door Current For Opening 4uA at Closing Door /Closing Door Warning Distance 20mm Installation Method Window Mounted PC，White Material &Color Main Body 23×19×60... -
Page 7: Package List
Package List ( Main Body + Base Of (Magnetic Part + Base of Main Body) *1 Magnetic Part)*1 Flat Cross-Recessed Self-Tapping Screw with Battery *1 Pointed Tail (ST3*12)*4 Manual Guarantee Card PE Form Tape *2 Manual *1 Guarantee Card *1... -
Page 8: Function Illustration
Function Illustration Battery Compartment Base of Main Main Body Body SET Key System Indicator Main Body Of Base Of Magnetic Magnetic Part Part... -
Page 9: Installation Steps
Installation Steps Step 1: Separate [Base of Main Body] & [Base of Magnetic Part] from their respective main body as per below illustration. Main Body Base of Main Body Main Body of Base of Magnetic Magnetic Part Part... - Page 10 Step 2: Option 1: Fix [Base of Main Body] on the door frame or window frame. [Base of Main Body] is fastened to the right position of door frame or window frame via 2 pieces of screw. Similarly, fix [Base of Magnetic Part] on the right position of door or window via 2 pieces of screw.
- Page 11 Option 2: Stick this product on the proper flat surface by the equipped PE form tape.Paste PE form tape on the base of product, and then stick the product in the selected place. Notes: Before installation, please keep the selected place tidy and clean.
- Page 12 Step 4: Aim [Main Body] & [Main Body of Magnetic Part] at the respective card slot of main body to fix them. Step 5: Installation Finish...
- Page 13 Join ZigBee Network 1.Before setting, please make sure the gateway (additional purchase) works normally. Ensure that power is supplied to this product, and it is within the effective communication range of the gateway.
- Page 14 2.Quickly click [Multi-Functional Key] 4 times to apply for joining ZigBee network, and each click is less than 1s. While searching networking, [System Indicator] is flashing. After joining ZigBee network successfully, [System Indicator] is on 2 seconds, and then goes out. Quickly click 4 times, and each click is less than 1s.
- Page 15 3.Long press [SET Key] 10 seconds. [System Indicator] flashes 4 times, then goes out to restore to factory setting. The default setting for factory setting does not join ZigBee network. Long press 10s Flashes 4 times , and then goes out...
- Page 16 User Guide After setting, user can control the monitor information of this product by smart mobile terminal. Once door frame or window frame is illegally open, this product will send alarm signal to smart mobile terminal so that user can know all to take corresponding measures.
- Page 17 Cautions ●Please do not install this product in the metal cover and other fully closed devices. It may result in network signal interrupt and low performance. ● Take routine tests periodically to find and remove trouble in case of any alarm for stealing. ●Avoid fall or sever collision for product to for fear of damage of internal part and impact on working life of product.
-
Page 18: Troubleshooting
Trouble Shooting How to deal with it when failed to join ZigBee network? Please confirm gateway works normally, and is allowed to add network, and this product iswithineffective communication range. How to handle it when it stays alarming in the early stage of installation? Please confirm main body of door contact matches that of magnetic parts, and size difference is within tolerance. -
Page 19: Purchasing Information
Purchasing Information Product Name Smart Contact Sensor Material & Color WL-ZSPDBPW-MT-01 Item No. PC，White Model WLPN1448200... -
Page 20: Software Download
Option B: Please visit our official website: http://www.wulian.cc/service.shtml for downloading. Warm prompt: For the first use, please download smart home APP and read user manual carefully. Please pay attention to Wulian information to download the latest APP in time. - Page 21 Statement: Hereby, Nanjing IOT Sensor Technology Co., Ltd. declares that this device is in compliance with theessential requirements and other relevant provisions of Directive 1999/5/ Disposal and Recycling Information You can help protect the environment! Please remember to respect the local regulations:hand in the non-working electrical equipments to an appropriate waste disposal centre The following marking is included in the product :...
- Page 22 Building 11, No.15, Fengji Road, Yuhuatai District, Nanjing (P. C.: 210039) Email: overseas@wuliangroup.com Service Hotline: 400-889-2891 www.wulian.cc...
