- Page 1 Smart Wall Socket-Outlet(UK Type) Model: WL-ZSKWNPW-W3160-01 User Manual Nanjing IoT Sensor Technology Co., Ltd (Wulian Co., Ltd) Publication No. ：2015-0611.V01...
- Page 2 ●Please read this product manual before using to ensure proper and safe use. ●Wulian smart wall socket-outlet (UK type, hereinafter referred to as “this product”) is one kind of smart home socket device of Nanjing IoT Sensor Technology Co., Ltd. (Hereinafter referred to as “our company”). This product need to be used with corresponding APP and accessories come with this product.
-
Page 3: Product Display
Product Display Power Status Power Status Indicator Light System Indicator Light Multi-function Key Buckle Button Decorative Cover Main Body... -
Page 4: Basic Function
Basic Function ●Advanced global burden shut off power protection, make your life more secure. ●You can control the appliance turn on or off and use the energy save function of timing via smart mobile terminal, thus realizing the smart home. ●Feedback the real-time status of the devices, support remote control with both local area network and internet . -
Page 5: Technical Parameters
Technical Parameters IEEE 802.15.4 PC、White Communication Way Material Color ZigBee/SmartRoom UL94 V-0 Wireless Type PCB Antenna Prevent Burning Rank Power Supply 230Vac， 50Hz Net Weight(g) Rated Max Electricity Wo r k i n g E n v i r o n - -10℃～+45℃... -
Page 6: Software Download
Scan the QR code on the product package, download the newest vision APP. The second method: Our official website: http://wulian.cc/english/service.html Note: Please read the user manual carefully at first use and follow our company news to upgrade the latest software in time. -
Page 7: Installation Instruction
Installation Instruction ① Connect this product with the wire of the wall box according to picture. Note: please make sure that the power has been turned off before installation. Electrical work is dangerous, non-professionals are not allowed to operate! Live line Null line Earth line... - Page 8 ②Take off decoration panel, fixed this product into the wall box with two screws. The installation method is same with the traditional one. ③Attach the decorative cover ,installation is complete，please finish the networking setting before the installation...
-
Page 9: Network Settings
Network Settings ①Setting—Join ZigBee network Quickly click Multi-function Key 4 times for applying to join ZigBee network. Upon successful connection, System Indicator Light will stay lit in green 2 seconds and then goes off. System Indicator Light goes off after staying lit in green 2 seconds Quickly click Multi-function Key 4... - Page 10 ② Setting--Binding Press Multi-function Key, quickly click switch button 1 time at the same time. Then loosen the Multi-function Key, the Indicator Light flash 1 time to transmit binding signal. Within 20 seconds, do the same operation on another binding device. Upon successful binding, the System Indicator Light will flicker 3 times in green and quick flicker 6 times if failed.
-
Page 11: Installation Precautions
Note: ●Please make sure the gateway (additional purchase) ZigBee network is working within effective communication distance of gateway before setting. If need remote control, please connect the gateway to the internet. ●When you want to add this product to another gateway, please quit current gateway and do the Installation Precautions ●Please cut off the power before installation! Electrical work is dangerous, non-professionals are not allowed to operate! -
Page 12: Order Information
Order Information Product Name Wulian Smart Wall Socket-Outlet(UK Type) Model WL-ZSKWNPW-W3160-01 Material and color PC,White Num. WLPN140522002... - Page 13 Wulian, is beside you More information, please follow our official website...
- Page 14 B11 Software Valley，No.15, Fengji Road, Yuhuatai District, Nanjing Postcode: 210039 Service hotline：400-889-2891 http://www.wulian.cc/english...
