Product Specifications - Itronix GoBook VR-1 Specifications

The rugged features your field deployed workers expect at
a price you can afford.
The very reliable GoBook VR-1 provides superior vibration, water ingress,
operating temperature and drop shock characteristics than typical semi-rugged
or consumer laptops. Fully optimized for your 'on-the-go' mobile workforce,
the vehicle-ready VR-1 can withstand extreme temperatures (-20° to 60° C
( -4° to 140° F)); humidity (95% RH); spills on the keyboard and palm rest area
(up to 100cc within five seconds); punishing 30 inch drops; and bone-jarring
vibrations from constant in-vehicle fleet use.
Performance
Not only did we outfit this laptop with ALL the rugged features you need, we
also included the powerful Intel Pentium
®
FSB, 2MB L2 cache. Utilizing the Intel ®
VR-1 enables advanced graphics manipulation for intense applications, while
maintaining speed and performance. And it even has an auto-adjusting LCD
screen that adapts to changing light conditions to conserve battery life.
Ultimate Wireless
Building on the Itronix legacy for high-performance enterprise wireless solutions,
the VR-1 offers a full range of radio options; simultaneously operating up to
four, including: Bluetooth, 802.11a/b/g, either 1xRTT / EV-DO or GPRS/ EDGE,
and an optional Integrated GPS module, which features a highly optimized
Quadrifilar Helix antenna for maximum satellite positioning access. For the
ultimate in mobility between networks, the VR-1 offers Netmotion software,
which allows users to dynamically and seamlessly travel in their active sessions
between LAN, WLAN, and WWAN. In addition, the unique Common Radio
Module Architecture Express (CRMA EXPRESS) allows for seamless plug-and-
®
play integration of radios as wireless technologies evolve, further extending the
'return on investment' (ROI) of your semi-rugged notebook computer.
Security
No we did not forget security, the VR-1 comes standard with a removable hard
disk drive and can be equipped with fingerprint scanner and Smart Card (CAC)
reader for secured access 'gate keeping'.

Product Specifications

Durability Features:
 Magnesium Alloy Case
Shock-Mounted Removable HDD

Shock Mounted Display

 Spill Resistant Keyboard and Palm Rest
Area
MIL-STD 810F vibration, temperature

and humidity
30" Drop Shock resistant (six drops)

CPU:
Intel 2.0 GHz Intel Pentium M Processor
 ® ® ®
+ 533 MHz FSB
2 MB L2 Cache

Storage & Memory:
40 GB removable shock mounted

6.35cm (2.5") HDD standard
80 GB HDD optional

Optional HDD Heater 40 GB and 80 GB

512MB DDRII DRAM standard, 512MB &

1024MB DDRII DRAM upgrades
512 MB base, upgradable to 1.0GB, 1.5GB,

and 2.0GB configurations
Display:
Shock Mounted 12.1" XGA Transmissive,

outdoor readable, TFT Active Matrix Color
LCD
Integrated Touch Panel

External video support up to 2048 x 1536 at

4 billion colors (32 bit color depth)
Video Graphics:
Intel 915GM Express Graphics Memory
 ®
Controller hub with Intel Graphics Media
®
Accelerator 900 featuring DVMT 3.0 and
128MB video memory
Audio:
Internal microphone and (2) speakers PCI

Audio with AC97 compliance
Expansion Slots:
Type II PC Card Slot, standard

Optional PCI Express

Optional SmartCard Reader

USA: 12825 E. Mirabeau Parkway • Spokane Valley, WA 99216 • Tel: +1-800-441-1309, +1-509-624-6600 • Fax: +1-509-626-4203 • Email: sales@gd-computing.com • www.gd-computing.com
Earlplace Business Park, Fletchamstead Highway, Coventry, CV4 9UR UK • Tel: +44(0) 24 7671 4800 • Fax: +44(0) 24 7671 5677 • Email: sales@gd-computing.co.uk • www.gd-computing.co.uk
EMEA:
France: Parc d'Affaires Silic, 74 Rue d'Arcueil, BP 10405, 94573 RUNGIS Cedex, France • Tel: +33(0) 1 46 87 80 09 • Fax: +33(0) 1 45 60 55 95 • Email: ventes@gd-computing.fr • www.gd-computing.fr
Germany: Mergenthalerallee 79, 65760 Eschborn, Germany • Tel: +49 211 5 23 91 459 • Fax: +49 211 5 23 91 200 • Email: vertrieb@gd-computing.de • www.gd-computing.de
2783 Thamesgate Dr., Mississauga, Ontario, L4T 1G5, Canada • Tel: +1-800-571-5434 • +1-905-672-7007 • Fax: 1-905-672-3999 • Email: sales@gd-computing.com • www.gd-computing.com
Canada:
Asia: 5th Floor-2, No. 80, Chung-Hsiao East Road Sec. 2, Taipei 100, Taiwan • Tel: +866 2 2393 0660 • Fax: +886 2 2395 5256 • Email: sales@gd-computing.com.tw
© 2007 General Dynamics. All rights reserved. General Dynamics Itronix reserves the right to make changes in its products and specifications at anytime and without notice. All trademarks indicated as such herein are trademarks of General Dynamics or
General Dynamics Itronix. All other product and service names are the property of their respective owners. ® Reg. U.S. Pat. and Tm. Off. V.2 03/07 4T
M 2.0 GHz Processor, 533 MHz
®
Graphics Media Accelerator 900 the
Multimedia Pocket:
 CD-RW Options: DVD-ROM/CD-RW or
DVD-RW/CD-RW
Keyboad & Input:
Standard notebook keyboard layout,

84 full-size 19mm pitch keys
3-button capacitive touch pad for optimum

bare hand operation
Interface:
56k modem, 10/100/1000 Ethernet

2x USB 2.0

PC card slot for (1)Type I, II, card with

32 bit card bus and support for zoomed
video
Built-in RJ-11 and RJ-45 jacks for integrated

fax/modem and Ethernet
USB 2.0 Connector for USB Peripherals

9 pin high speed serial port

 68 pin multi I/O docking connector
15 pin external video (CRT) port

External speaker and microphone jacks

 Optional Smart Card reader and PCI
EXPRESS
Wireless LAN:
Intel PRO/Wireless 2915ABG network
 ®
connections 802.11a/b/g
Integrated Wireless Communications
(Options):
Wireless WAN includes 1xRTT / EV-DO or

GPRS/ EDGE
Wireless LAN includes Intel PRO/Wireless

2915ABG;
 Bluetooth (various combinations available
depending specific requirements)
GPS is also available as a fully integrated

option
The GPS Quadrifilar Helix antenna is

located in the top of the display housing
to optimize GPS performance
Up to 4 RF modems can be integrated at

one time
Common Radio Module Architecture

(CRMA) Express with fully integrated,
rugged and user replaceable WWAN
radio modules
 Supports PCMCIA in the PC Card Slot and
OEM radio modules
Engineered for minimum radio desense for

maximum wireless coverage
Superior wireless power management.

Integrated Wireline Communications:
56 Kbps V.92 fax/modem with 10/100/1000M

bit Ethernet LAN standard
Mini PCI performance/protected modem

available for more demanding applications.
Power Supply:
Smart 4400 mAH (47.52W) Lithium Ion main

Battery & AC Adapter
Battery life of 4-5. hours with user-

selectable Battery Management utility
Optional Smart 6600 mAH (71.2W) Lithium

Ion main Battery pack upgrade.
Software:
 Microsoft Windows XP
Enhanced Security & Pr otection:
 Optional Fingerprint scanner
Smart Card (CAC Card) Reader

Kensington Lock

 SuperPassword
Pre-boot Password

Warranty:
3 year warranty, with additional extensions

available based on service parts
Dimensions & Weight:
1.7" (H) x 11.5" (W) x 9.8" (D) (4.32 cm.

(H) x 29.21 cm. (W) x 24.89 cm. (D))
5.8lbs (2.63 kg)

Integrated Options:
Bluetooth USI Class II Antenna

 GPS Module w/ Integrated Sarantel
Antenna
CRMA Express - CDMA (1xRTT/EV-DO)

CRMA Express - GSM (GPRS/EDGE)

CRMA Express - UMTS European

Pointing Device:
3-Button touch pad controls

Optional touch screen

Accessories:
Vehicle Cradle w/ RF Connectors

Vehicle Cradle w/o RF Connectors

Office Dock

Standard Battery (6 cells)

Extended Battery (9 cells)

AC Adapter & Cord (65W)

Vehicle Adapter - 12V (70W)

Vehicle Adapter - 24V (70W)

Soft Handle & Hardware Kit

Shoulder Strap & Hardware Kit

Office dock

Vehicle dock with lock, power

(2) USB Interfaces, and RF contacts for

external vehicle-mounted antennas (the
vehicle dock has more connections than
are listed)
Carry cases for system and accessories;

NetMotion Mobility XE, providing seamless

roaming connectivity.
Other Options:
 Express Card
Smart Card Reader

Stylish Hard Handle

 Fingerprint Scanner
Custom Labels

Custom Disk Image

Environmental Specifications:
Die-cast magnesium for all structural

components
Operating temperature -20° to 60° C

(-4° to 140° F) with optional hard drive
heater
Vibration per MIL-STD 810F, 514.5 and

ASTM 4169-99 truck assurance level II,
schedule E.
30" drop tested

