  • Page 1 ROME2D32GM-2T ROME2D32GM-NL User Manual Version 1.0 Published January 2022 Copyright©2022 ASRock Rack INC. All rights reserved.
  • Page 2 In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,...

  • Page 4: Table Of Contents

    Installation of Memory Modules (DIMM) Jumper Setup Onboard Headers and Connectors Dr. Debug Identification purpose LED/Switch Driver Installation Guide 2.10 Dual LAN and Teaming Operation Guide (ROME2D32GM-2T only) 2.11 M.2_SSD (NGFF) Module Installation Guide Chapter 3 UEFI Setup Utility Introduction 3.1.1 UEFI Menu Bar...
  • Page 5 3.1.2 Navigation Keys Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 ACPI Configuration 3.3.5 USB Configuration 3.3.6 Super IO Configuration 3.3.7 Serial Port Console Redirection 3.3.8 H/W Monitor 3.3.9 PCI Subsystem Settings 3.3.10 AMD CBS 3.3.11 AMD PBS 3.3.12 PSP Firmware Versions 3.3.13 Tls Auth Configuration...
  • Page 6 Boot Screen 3.6.1 CSM Parameters Event Logs Exit Screen Chapter 4 Software Support Install Operating System Support CD Information 4.2.1 Running The Support CD 4.2.2 Drivers Menu 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 8: Specifications

    1.2 Specifications ROME2D32GM-2T / ROME2D32GM-NL MB Physical Status Form Factor Proprietary Dimension 16.5” x 13.81” (42 cm x 35.1 cm) Processor System AMD EPYC™ 7002 Generation Processors Socket Dual Socket P, LGA3647 Thermal Design 225W Power CPLD LCMXO3LF-2100C System Memory...
  • Page 9 ROME2D32GM-2T ROME2D32GM-NL Management BMC Controller ASPEED AST2500 IPMI Dedicated 1 x Realtek RTL8211E for dedicated management GLAN GLAN Features - Watch Dog - NMI Graphics Controller ASPEED AST2500 VRAM DDR4 256MB Rear Panel I/O VGA Port 1 (D-sub) USB 3.2 Gen1 Port...
  • Page 10 256Mb AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8 Support - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU Temperature Sensing - System Temperature Sensing - Card Side Temperature Sensing...
  • Page 11 ROME2D32GM-2T ROME2D32GM-NL This motherboard supports Wake from on Board LAN. To use this function, please make sure that the “Wake on Magic Packet from power off state” is enabled in Device Manager > Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is enabled in UEFI SETUP UTILITY >...

  • Page 12: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 13: Motherboard Layout

    UID1 ASPEED 2500 PWR_BTN1 DDR4_M1 RST_BTN DDR4_M2 BIOS NMI_BTN DDR4_N1 NCSI1 DDR4_N2 HDD_SYS_LED DDR4_O1 DDR4_O2 IPMI_LAN1 DDR4_P1 DDR4_P2 X550_LAN1 (ROME2D32GM-2T only) DDR4_D2 DDR4_D1 X550_LAN2 DDR4_C2 (ROME2D32GM-2T only) DDR4_C1 SLIM4_1 DDR4_B2 NUT110_1 SLIM4_2 DDR4_B1 DDR4_A2 DDR4_A1 SLIM3_1 NUT80_1 SLIM3_2 LCM1 PWM_CFG1...
  • Page 14 Description ATX Power Connector (ATXPWR1) System Fan Connector (FAN5) ATX 12V Power Connector (ATX12V2) System Fan Connector (FAN6) 4 x 288-pin DDR4 DIMM Slots (DDR4_I1, DDR_J1, DDR4_K1, DDR4_L1)* 4 x 288-pin DDR4 DIMM Slots (DDR4_I2, DDR_J2, DDR4_K2, DDR4_L2)* System Fan Connector (FAN8) System Fan Connector (FAN7) SlimSAS Connector (SLIM9_1) SlimSAS Connector (SLIM9_2)
  • Page 15 ROME2D32GM-2T ROME2D32GM-NL No. Description System Fan Connector (FAN1) IPMI LAN LED Header (IPMI_LED1) System Panel Header (PANEL1) Auxiliary Panel Header (AUX_PANEL1) TPM Header (TPM1) NCSI Mode Jumper (NCSI_SEL1) Chassis ID Jumper (CHASSIS_ID2) Intelligent Platform Management Bus Header (IPMB_1) BMC SMBus Header (BMC_SMB_3)
  • Page 16 No. Description Front VGA Header (FRONT_VGA1) SlimSAS Connector (SLIM10_2) SlimSAS Connector (SLIM10_1) COM Port Header (COM1) USB 3.2 Gen1 Header (USB3_7_8) PSU SMBus Header (PSU_SMB1) * For DIMM installation and configuration instructions, please see p.20 (Installation of Memory Modules (DIMM)) for more details.

  • Page 17: Onboard Led Indicators

    ROME2D32GM-2T ROME2D32GM-NL 1.5 Onboard LED Indicators Dr. Debug...
  • Page 18 Item Status Description FAN_LED8 FAN8 failed FAN_LED7 FAN7 failed FAN_LED3 FAN3 failed FAN_LED4 FAN4 failed FAN_LED2 FAN2 failed FAN_LED1 FAN1 failed SB_PWR1 Green STB PWR ready BMC_LED1 Green BMC heartbeat LED FAN_LED6 FAN6 failed FAN_LED5 FAN5 failed...

  • Page 19: I/O Panel

    USB 3.2 Gen1 Ports (USB3_3_4) HDD/System Fault LED (HDD_SYS_LED) VGA Header (VGA1) IPMI LAN Header (IPMI_LAN1)* 10G LAN RJ-45 Port (X550_LAN1)** UID Switch (UID) (ROME2D32GM-2T only) 10G LAN RJ-45 Port (X550_LAN2)** Power Switch/LED (PWR_BTN1) 11 (ROME2D32GM-2T only) Reset Button (RST_BTN) LAN Port LED Indications *There are two LED next to the LAN port.
  • Page 20 *There are two LED next to the LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 10G LAN Port (X550_LAN1, X550_LAN2) LED Indications (ROME2D32GM-2T only) Activity / Link LED Speed LED Status Description...

  • Page 21: Block Diagram

    ROME2D32GM-2T ROME2D32GM-NL 1.7 Block Diagram ROME2D32GM-2T...
  • Page 22 ROME2D32GM-NL...

  • Page 23: Chapter 2 Installation

    ROME2D32GM-2T ROME2D32GM-NL Chapter 2 Installation This is a Proprietary form factor (16.5’’ x 13.81’’, 42.0 cm x 35.1 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 24: Installing The Cpu

    2.3 Installing the CPU 1. Before you insert the CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 25 ROME2D32GM-2T ROME2D32GM-NL...
  • Page 26 Carr ier Frame with CPU Rail Frame Please make sure that the carrier frame with CPU is closely attached to the rail frame while inserting it. Install the carrier frame with CPU. Don’t separate them.
  • Page 27 ROME2D32GM-2T ROME2D32GM-NL...

  • Page 28: Installation Of Memory Modules (Dimm)

    2.4 Installation of Memory Modules (DIMM) This motherboard provides thirty-two 288-pin DDR4 (Double Data Rate 4) DIMM slots in two groups, and supports Eight Channel Memory Technology. CPU1 CPU2 DDR4_A1, B1, C1, D1, E1, F1, G1, H1 DDR4_I1, J1, K1, L1, M1, N1, O1, P1 DDR4_A2, B2, C2, D2, E2, F2, G2, H2 DDR4_I2, J2, K2, L2, M2, N2, O2, P2 1.
  • Page 29 ROME2D32GM-2T ROME2D32GM-NL Recommended Memory Configurations 1 CPU Configurations DIMM(S) CPU1 The symbol # indicates the slot is populated.
  • Page 30 2 CPU Configurations DIMM(S) CPU1 CPU2 The symbol # indicates the slot is populated.
  • Page 31 ROME2D32GM-2T ROME2D32GM-NL...

  • Page 32: Jumper Setup

    2.5 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
  • Page 33 ROME2D32GM-2T ROME2D32GM-NL Chassis ID0 Jumper (3-pin CHASSIS_ID0) (see p.6, No. 44) Chassis ID1 Jumper (3-pin CHASSIS_ID1) (see p.6, No. 46) Chassis ID2 Jumper (3-pin CHASSIS_ID2) Reserved for system level Reserved for system level (see p.6, No. 40)

  • Page 34: Onboard Headers And Connectors

    2.6 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header C onnec t t he power sw itch, PLED+ PLED-...
  • Page 35 ROME2D32GM-2T ROME2D32GM-NL Auxiliary Panel Header This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.6, No. 37) including front panel SMB, internet status indicator. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows you to connect SMBus (System Management Bus) equipment. It can be used for communication between peripheral equipment in the system, which has slower transmission rates, and power management equipment.
  • Page 36 IntA_PA_D+ USB 3.2 Gen1 Headers Besides four default USB 3.2 IntA_PA_D- (19-pin USB3_5_6) Gen1 ports on the I/O panel, IntA_PA_SSTX+ IntA_PA_SSTX- (see p.6, No. 33) there are two USB 3.2 Gen1 IntA_PA_SSRX+ (19-pin USB3_7_8) headers on this motherboard. IntA_PA_SSRX- Vbus (see p.6, No.
  • Page 37 ROME2D32GM-2T ROME2D32GM-NL Backplane PCI Express These headers are used for the Hot-Plug Connectors hot plug feature of HDDs on (5-pin CPU1_ HSBP1) the backplane. P0_HP_ALERT_L (see p.6, No. 48) CPU_HP_SDA (5-pin CPU2_ HSBP1) CPU_HP_SCL (see p.6, No. 47) System Fan Connectors...
  • Page 38 SPI TPM Header This connector supports SPI (13-pin SPI_TPM_J1) Trusted Platform Module SPI_DQ3 SPI_DQ2 SPI_CS0 SPI_PWR (see p.6, No. 66) (TPM) system, which can Dummy SPI_MISO securely store keys, digital RSMRST# SPI_MOSI certificates, passwords, and RST# SPI_TPM_CS# data. A TPM system also helps TPM_PIRQ enhance network security, protects digital identities, and...
  • Page 39 ROME2D32GM-2T ROME2D32GM-NL LINK_LEDN IPMI LAN LED Header This header is used to connect LINK_LEDP LED0_AD0 (4-pin IPMI_LED1) to the LED indicators on the LILEDP (see p.6, No. 35) chassis. NCSI Header The onboard NCSI header is NCSI_CLK_IN (9-pin NCSI1) used for external connections..
  • Page 40 Slimline SAS Connectors These connectors are used for Right-Angle: the NVME PCIE devices. (SLIM1_1) (see p.6, No. 24) (SLIM1_2) (see p.6, No. 25) (SLIM2_1) (see p.6, No. 22) (SLIM2_2) (see p.6, No. 23) (SLIM6_1) (see p.6, No. 15) (SLIM6_2) (see p.6, No. 16) (SLIM7_1) (see p.6, No.

  • Page 41: Dr. Debug

    ROME2D32GM-2T ROME2D32GM-NL 2.7 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31...
  • Page 42 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 43 ROME2D32GM-2T ROME2D32GM-NL 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 44 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 45 ROME2D32GM-2T ROME2D32GM-NL 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 46 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 47: Identification Purpose Led/Switch

    ROME2D32GM-2T ROME2D32GM-NL 2.8 Identification purpose LED/Switch With the UID button, You are able to locate the server you’re working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed,...

  • Page 48: Dual Lan And Teaming Operation Guide

    2.10 Dual LAN and Teaming Operation Guide (ROME2D32GM-2T only) Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images.

  • Page 49: M.2_Ssd (Ngff) Module Installation Guide

    ROME2D32GM-2T ROME2D32GM-NL 2.11 M.2_SSD (NGFF) Module Installation Guide The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket supports a M.2 PCI Express module up to Gen4 x4 (64GT/s).
  • Page 50 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 51: Chapter 3 Uefi Setup Utility

    ROME2D32GM-2T ROME2D32GM-NL Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer. Please press <F2> or <Del> during the Power-On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 52: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 53: Main Screen

    ROME2D32GM-2T ROME2D32GM-NL 3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 54: Advanced Screen

    3.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, PCI Subsystem Settings, AMD CBS, AMD PBS, PSP Firmware Versions, Tls Auth Configuration, Network Stack Configuration and Instant Flash.

  • Page 55: Cpu Configuration

    ROME2D32GM-2T ROME2D32GM-NL 3.3.1 CPU Configuration SVM Mode Enable or disable CPU Virtualization. Node 0 Information View Memory Information related to Node 0. Node 1 Information View Memory Information related to Node 1.

  • Page 56: Chipset Configuration

    3.3.2 Chipset Configuration PCIe Compliance Mode Use thie item to confogure the PCIe Link Compliance Mode. SPI/LPC TPM Switch Configure SPI/LPC TPM switch settings. OnBrd/Ext VGA Select Select between onboard or external VGA support. SLIM3_1 PCIE/SATA Mode Configure SLIM3_1 PCIE/SATA Mode. SLIM4_1 PCIE/SATA Mode Configure SLIM4_1 PCIE/SATA Mode.
  • Page 57 ROME2D32GM-2T ROME2D32GM-NL SLIM1_1/SLIM1_2 Link Width This allows you to select SLIMLINE Link Width. The default value is [x16]. SLIM2_1/SLIM2_2 Link Width This allows you to select SLIMLINE Link Width. The default value is [x16]. SLIM3_1/SLIM3_2 Link Width This allows you to select SLIMLINE Link Width. The default value is [x16].
  • Page 58 SLIM5_1 Slot Link Speed This allows you to select SLIMLINE Slot Speed. The default value is [Auto]. SLIM6_1/SLIM6_2 Link Speed This allows you to select SLIMLINE Slot Speed. The default value is [Auto]. SLIM7_1/SLIM7_2 Link Speed This allows you to select SLIMLINE Slot Speed. The default value is [Auto]. SLIM8_1/SLIM8_2 Link Speed This allows you to select SLIMLINE Slot Speed.

  • Page 59: Storage Configuration

    ROME2D32GM-2T ROME2D32GM-NL 3.3.3 Storage Configuration SATA Hot Plug Enable/disable the SATA Hot Plug Function.

  • Page 60: Acpi Configuration

    3.3.4 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. RTC Alarm Power On Use this item to enable or disable RTC (Real Time Clock) to power on the system.

  • Page 61: Usb Configuration

    ROME2D32GM-2T ROME2D32GM-NL 3.3.5 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled].

  • Page 62: Super Io Configuration

    3.3.6 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Serial Port Address Use this item to select an optimal setting for Super IO device. SOL Configuration Use this item to set parameters of SOL.

  • Page 63: Serial Port Console Redirection

    ROME2D32GM-2T ROME2D32GM-NL 3.3.7 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection.
  • Page 64 Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
  • Page 65 ROME2D32GM-2T ROME2D32GM-NL Redirect After POST When Bootloader is selected, then Legacy Console Redirection is disabled before booting to legacy OS. When Always Enable is selected, then Legacy Console Redirection is enabled for legacy OS. Default setting for this option is set to Always Enable.

  • Page 66: H/W Monitor

    3.3.8 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage. Watch Dog Timer This allows you to enable or disable the Watch Dog Timer.

  • Page 67: Pci Subsystem Settings

    ROME2D32GM-2T ROME2D32GM-NL 3.3.9 PCI Subsystem Settings Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding). SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO...

  • Page 68: Amd Cbs

    3.3.10 AMD CBS CPU Common Options Use this item to configure CPU Common options. DF Common Options Use this item to configure DF Common options. UMC Common Options Use this item to configure UMC Common options. NBIO Common Options Use this item to configure NBIO Common options. FCH Common Options Use this item to configure FCH Common options.

  • Page 69: Amd Pbs

    ROME2D32GM-2T ROME2D32GM-NL 3.3.11 AMD PBS Use this item to configure AMD CPM RAS related settings.

  • Page 70: Psp Firmware Versions

    3.3.12 PSP Firmware Versions The PSP Firmware Verions displays the version information of PSP Recovery BL, PSP BootLoader, SMU FW, ABL, APCB, APDB, and APPB.

  • Page 71: Tls Auth Configuration

    ROME2D32GM-2T ROME2D32GM-NL 3.3.13 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert.

  • Page 72: Network Stack Configuration

    3.3.14 Network Stack Configuration Network Stack Use this item to enable or disable UEFI Network Stack. Ipv4 PXE Support Use this item to enable or disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available. Ipv4 HTTP Support Use this item to enable or disable IPv4 HTTP boot support.
  • Page 73 ROME2D32GM-2T ROME2D32GM-NL PXE boot wait time Wait time in seconds to press ESC key to abort the PXE boot. Use either +/- or numeric keys to set the value. Media detect count Number of times the presence of media will be checked. Use either +/- or numeric keys to...

  • Page 74: Instant Flash

    3.3.15 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive, floppy disk or hard drive and launch this tool, then you can update your UEFI only in a few clicks without preparing an additional floppy diskette or other compli- cated flash utility.

  • Page 75: Server Mgmt

    ROME2D32GM-2T ROME2D32GM-NL 3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces.

  • Page 76: System Event Log

    3.4.1 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 77: Bmc Network Configuration

    ROME2D32GM-2T ROME2D32GM-NL 3.4.2 BMC Network Configuration Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No].
  • Page 78 The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/ipmi.asp IPV6 Support Enable or Disable LAN1 IPV6 Support.

  • Page 79: Bmc Tools

    ROME2D32GM-2T ROME2D32GM-NL 3.4.3 BMC Tools Load BMC Default Settings Use this item to load BMC default settings. KCS control Select the KSC interface state after POST end. If [Enabled] is selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS...

  • Page 80: Security

    3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 81: Key Management

    ROME2D32GM-2T ROME2D32GM-NL 3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode.
  • Page 82 a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed Key Exchange Keys Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin)
  • Page 83 ROME2D32GM-2T ROME2D32GM-NL Forbidden Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...
  • Page 84 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Default, External, Mixed...

  • Page 85: Boot Screen

    ROME2D32GM-2T ROME2D32GM-NL 3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order.
  • Page 86 Setup Prompt Timeout Configure the number of seconds to wait for the UEFI setup utility. Bootup Num-Lock If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled]. AddOn ROM Display Use this option to adjust AddOn ROM Display.

  • Page 87: Csm Parameters

    ROME2D32GM-2T ROME2D32GM-NL 3.6.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows Server 2012 R2 or later ver- sions 64-bit UEFI and all of your devices support UEFI, you may also disable CSM for faster boot speed.
  • Page 88 SLIM1_2-1 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.) SLIM1_2-2 Slot OpROM Use this item to select slot storage and Network Option ROM policy.
  • Page 89 ROME2D32GM-2T ROME2D32GM-NL SLIM3_2-1 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.) SLIM3_2-2 Slot OpROM Use this item to select slot storage and Network Option ROM policy.
  • Page 90 SLIM6_1-1 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.) SLIM6_1-2 Slot OpROM Use this item to select slot storage and Network Option ROM policy.
  • Page 91 ROME2D32GM-2T ROME2D32GM-NL SLIM8_1-1 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.) SLIM8_1-2 Slot OpROM Use this item to select slot storage and Network Option ROM policy.
  • Page 92 SLIM10_1-1 Slot OpROM Use this item to select slot storage and Network Option ROM policy. In Auto option, the default is Disabled with NVMe device, but it is Legacy with other devices. (This item can't select Video Option ROM policy.) SLIM10_1-2 Slot OpROM Use this item to select slot storage and Network Option ROM policy.

  • Page 93: Event Logs

    ROME2D32GM-2T ROME2D32GM-NL 3.7 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 94 entries which utilize a multiple-event counter. The value ranges from 0 to 99 minutes. Log EFI Status Code Enable or disable the logging of EFI Status Codes as OEM reserved type E0 (if not already converted to legacy). Convert EFI Status Codes to Standard Smbios Type Enable or disable the converting of EFI Status Codes to Standard Smbios Types (Not all may be translated).

  • Page 95: Exit Screen

    ROME2D32GM-2T ROME2D32GM-NL 3.8 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY.

  • Page 96: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 97: Chapter 5 Troubleshooting

    ROME2D32GM-2T ROME2D32GM-NL Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 98 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 99: Technical Support Procedures

    ROME2D32GM-NL 5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.
