Helmets
•
Always wear a helmet. Wearing a helmet properly may reduce the
risk of a severe head injury. When riding, always wear a helmet that
meets or exceeds the standards of the Consumer Product Safety
Commission (CPSC). Check the manual that comes with your
helmet.
•
Ensure your helmet fits your head and is properly secured. If you
attach a child's seat to the bicycle, the child must wear a properly
fitted helmet at all times.
•
Read your helmet manual to make sure it is adjusted properly
according to the fitting instructions provided by the helmet
manufacturer.
•
A proper-fitting helmet should be comfortable and should neither
rock forward/backward nor side to side.
Pre-Ride Safety Check
•
Before each ride, inspect your eBike for damage. If damage is
found, do not ride.
•
Verify that the front and rear axles are secure.
•
Verify that the handlebar and seat clamps are closed and
tightened to the torque specified in the Owner's Manual.
•
Verify that both the handlebar latch and frame latch are secure
and fully closed.
•
Check tire pressure of both wheels.
•
Pull the brake levers to ensure the brakes are working properly
and adjust if necessary.
•
NEVER exceed the maximum total weight limit of 275 lbs. (125
kg). The rear rack can hold a maximum of 55 lbs. (25 kg). As an
example, if you have 40 lbs. (18 kg) of cargo, then the maximum
weight of the rider would be 235 lbs. (107 kg)
WARNING!
•
Refer to the tightening torque section (p.19) of this manual in
to properly torque the chain tensioner and make sure it
correct position for proper function. If the chain is too tight and you
are walking the bike in PAS 1-5, the front chainring and pedals will
move which will cause PAS to activate. The acceleration from this
activation could cause a crash. To avoid this, walk the bike in PAS 0.
L E CT R I C E B I K E S.C O M | 602.715.0907
order
is in the
7
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the XP Lite and is the answer not in the manual?
Questions and answers
Resetting the odometer
To reset the odometer on a Lectric XP Lite, hold the plus (+) button for 5 seconds.
This answer is automatically generated
how to properly install chain guard?
To properly install the chain guard on a Lectric XP Lite:
1. Remove the six screws around the perimeter of the pulley belt guard and take off the front part of the guard.
2. Use an 8 mm hex wrench to unscrew and remove the crank bolt.
3. Use a crank puller tool to remove the pulley.
4. Remove the rear part of the belt guard.
5. Place the new chain guard behind the chain stay.
6. Line up the front mounting tab with the mounting point behind the pulley and insert a 4 mm bolt.
7. Line up the rear mounting tab with the rear mounting point on the chain stay and insert another 4 mm bolt.
8. Reinstall the pulley, crank, and belt.
This process requires removing existing parts and using specific tools like a crank puller and hex wrench.
This answer is automatically generated
Serial number on XP Lite 2.0
