CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
1
Chair/Bench left frame
2
Chair/Bench right frame
3
Bench seat frame
4
Chair seat frame
5
Bench back frame
6
Chair back frame
7
Table feet frame
8
Table side frame
9
Bench seat cushion
10
Chair seat cushion
11
Table glass
A
A llen bolt(M6x40 mm)
B
A llen bolt(M6x60 mm)
C
Flat washer
D
Allen key
QUANTITY
3X
3X
1X
2X
1X
2X
2X
2X
1X
2X
1X
34X
6X
40X
3X
Weight Capacity : 275 Lbs (single seat)
Warning : Do not stand on bench
Warning : Do not over torque bolts/screws
Model# PAT7507
Product Dimensions:
39.76"x24.80"x32.67" H (Bench)
22.83"x24.80"x32.67" H (Chair)
30.11"x16.53"x14.76" H (Table)
550 Lbs (towperson seat)
1-3
