CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
1
Bench left frame
2
Bench back frame
3
Bench seat frame
4
Bench front frame
5
Bench right frame
6
Bench seat cushion
7
Bench back cushion
8
Corner right frame
9
Corner back frame
10
Corner seat frame
11
Corner front frame
12
Corner left frame
13
Corner seat cushion
14
Corner back cushion
A
Allen bolt(M6x25 mm)
B
Allen bolt(M6x35 mm)
Plastic feet
C
D
Flat washer
E
Allen key
QUANTITY
1X
1X
1X
1X
1X
2X
2X
1X
1X
1X
1X
1X
1X
1X
32X
14X
8X
30X
2 X
Weight Capacity : 275 Lbs (single seat)
Warning : Do not stand on chair
Warning : Do not over torque bolts/screws
Model# PAT7509 - 1/2
Product Dimensions:
51.96"x26.77"x25.98" H (Bench)
26.77"x26.77"x25.98" H (Corner)
26.77"x26.77"x13.97" H (Table)
26.77"x26.77"x13.97" H (Stool)
550 Lbs (towperson seat)
1- 4
