CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
DESCRIPTION
PIECE
Chair/Bench Left Frame
1
2
Chair/Bench Right Frame
Bench Back Frame
3
Bench Seat Frame
4
5
Chair Back Frame
6
Chair Seat Frame
Table Side
7
Table Apron
8
Glass Table
9
Chair Cushion
10
Bench Cushion
11
A
Allen bolt(M6x25mm)
B
Allen bolt(M6x40 mm)
C
Flat washer
D
Allen key
QUANTITY
3X
3X
1X
1X
2X
2X
2X
2X
1X
2X
1X
20X
24X
44X
1X
Weight Capacity : 275 Lbs (single seat)
550 Lbs (towperson seat)
Warning : Do not stand on chair
Warning : Do not over torque bolts/screws
Model# PAT7504
Product Dimensions:
41.73"x23.23"x33.07" H (Bench)
23.23"x23.23"x33.07" H (Chair)
28.35"x16.54"x15.35" H (Table)
1-3
