CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
1
Chair/Bench left frame
2
Chair/Bench right frame
3
Bench seat frame
4
Chair seat frame
5
Bench back frame
6
Chair back frame
7
Table top
8
Right leg table
9
Left leg table
10
Table botton frame
11
Bench seat cushion
12
Chair seat cushion
13
Table glass
A
Allen bolt(M6x20 mm)
Allen bolt(M6x 30 mm)
B
C
Allen bolt(M6x 40 mm)
D
Allen bolt(M6x60 mm)
E
Flat washer
F
Allen key
QUANTITY
3X
3X
1X
2X
1X
2X
1X
1X
1X
1X
1X
2X
1X
4X
1 0X
24X
6 X
4 4X
3 X
Weight Capacity : 275 Ibs (single seat)
Warning : Do not stand on bench
Warning : Do not over torque bolts/screws
Model# PAT7505A
Product Dimensions:
42.51"x20.86"x31.49" H (Bench)
22.44"x20.86"x31.49" H (Chair)
26.77"x14.96"x16.14" H (Table)
550 Ibs (towperson seat)
1-3
