CARE AND MAINTENANCE
Store outdoor furniture indoors or cover well when not in use.
Remove wooden furniture from standing water. Dust regularly with small brush or vacuum
Spills should be taken care of immediately before they harden or
stain with a slightly dampened sponge.
NOTICE
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* This item may require periodic tightening
Part List and Hardware List
PIECE
DESCRIPTION
1
Chair/Bench left frame
2
Chair/Bench right frame
3
Bench back frame
4
Chair back frame
5
Bench seat frame
6
Bench front frame
7
Chair seat chair
8
Chair front frame
9
Bench seat cushion
10
Chair seat cushion
11
Chair/Bench back cushion
12
Leg table
13
Table botton frame
14
Table glass
Allen bolt(M6x 30 mm)
A
B
Allen bolt(M6x 40 mm)
C
Allen bolt(M6x60 mm)
D
Flat washer
E
Allen key
QUANTITY
3X
3X
1X
2X
1X
1X
2X
2X
1X
2X
4X
2X
1X
1X
17 X
2 8 X
6X
5 1 X
3X
Weight Capacity : 275 Lbs (single seat)
Warning : Do not stand on chair
Warning : Do not over torque bolts/screws
Model# PAT7516
Product Dimensions:
48.82"x26.38"x29.92" H (Bench)
25.98"x26.38"x29.92" H (Chair)
36.22"x22.04"x17.12" H (Table)
550 Lbs (towperson seat)
1-3
