- Page 1 INSTALLATION VIDEO Swing Down Baby Bed Rail INSTRUCTION MANUAL #2774 90cm 45cm (35.4”) (17.7”) WIDE TALL IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE. This product complies with safety standard BS7972:2001+A1:2009...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION General Maintenance Warnings 04-05 WHAT’S IN THE BOX Parts INSTALLATION Bar Installation Mesh & Underbar Installation Positioning the Bed Rail 9-10 Minimum Distance OPERATION How to Operate Cleaning Instructions SUPPORT Warranty Certificate Warranty Card After Sales Support... -
Page 3: Safety Information
SAFETY INFORMATION GENERAL Read this instruction manual carefully and keep it in a safe place for future reference. The correct use and maintenance of this product is essential. MAINTENANCE Regularly check that the product is functioning correctly, lubricate hinges and moving components. Tighten and adjust mounts to ensure secure smooth operation. -
Page 4: Warnings
WARNING • Adult assembly required. • Carefully read all instructions before assembly and use of the product. • Dispose of all packaging materials carefully after assembly. • Not suitable for use of children under the age of 18 months or when the child is over the age of 5 years. - Page 5 WARNING • Additional and replacement parts shall be obtained only from the manufacturer. • This Bed Rail should not be used on a sleeping surface that is more than 600mm (23.6”) from the floor. • To prevent risk of strangulation it is essential to ensure that when the Bed Rail is fitted into position, there is a gap of at least 250mm (9.8”), between each end of the bed and the corresponding end of the Bed Rail.
-
Page 6: What's In The Box
WHAT’S IN THE BOX PARTS 1 x Bed Rail Mesh 1 x Upper Support Bar 2 x Under Bar with Strap 1 x Bottom Support Bar... -
Page 7: Installation
INSTALLATION Step 1. Bar Installation 1. Insert Upper Support Bar into Bottom Support Bar. Make sure the spring pin fits securely into opposing hole so that the two pieces cannot pull apart. 2. Connect the two sides. Make sure the spring pin fits securely into opposing hole so that the bed rail cannot pull apart. -
Page 8: Mesh & Underbar Installation
INSTALLATION Step 2. Mesh & Underbar Installation 1. To install the Mesh on the Bed Rail, slide the Mesh over the Support Bars until it reaches the other end and zip it shut. 2. Insert the plastic hinge into the assembled panel and press in the metal spring button to fully insert the tube into the hole in the plastic hinge. -
Page 9: Positioning The Bed Rail
INSTALLATION Step 3. Positioning the Bed Rail 1. Set up the Bed Rail in locked position. Place the Bed Rail on the side of the bed that you would like to have protected, place the fixed plate with strap on the opposite side of the Bed Rail and mount the outer edge of the box spring. - Page 10 INSTALLATION 2. Check to make sure the left and right Underbar assemblies are parallel to one another, then place the mattress on the top the assembly.
-
Page 11: Minimum Distance
INSTALLATION Minimum Distance Warning! To prevent the rist of strangulation, it is essential to ensure that when the Bed Rail is fitted into position, there is at least 250mm (10”) between each end of the bed and the corresponding end of the Bed Rail MIN 10”... -
Page 12: Operation
OPERATION HOW TO OPERATE Folding Up Bed Rail Swing up the Bed Rail, turn the locking tabs and hold them at unlocked position. Continue to swing until the panel touches the side of the mattress. Let go of the locking tabs and the Bed Rail will be locked into in-use position. -
Page 13: Cleaning Instructions
CLEANING INSTRUCTIONS Simply use a soft damp cloth to wipe the Bed Rail, dry after cleaning. Do not use chemical or abrasive cleaners. -
Page 14: Support
SUPPORT WARRANTY CERTIFICATE Congratulations! You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults, we will provide you with a warranty against defects as follows: WARRANTY The product is guaranteed to be free from from defects in workmanship and parts for a period of 12 months from the date of purchase. -
Page 15: Warranty Card
SUPPORT WARRANTY CARD DETAILS: Baby Bed Rail PRODUCT NAME: 2774 PRODUCT NUMBER: YOUR NAME: ADDRESS: PHONE: EMAIL: DATE OF PURCHASE: LOCATION OF PURCHASE: We recommend that you keep a copy of your receipt, showing the date of purchase, with this warranty certificate and keep for your reference. - Page 16 Scan the QR code for Live Chat Support or visit: permachildsafety.com/contact-us Perma Child Safety @permachildsafety...
