- Page 1 INSTALLATION VIDEO Extra Wide Barrier INSTRUCTION MANUAL 73cm - 194cm 75cm (28.8” - 76.38”) (29.5”) #2748 White FITS OPENINGS TALL IMPORTANT! READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP FOR FUTURE REFERENCE. This product complies with safety standard EN12227:2010...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION General Maintenance Warnings 04-05 Mountings / Tools Required 06-07 WHAT’S IN THE BOX Parts 08-09 INSTALLATION Barrier Placement & Configuration Underside Bracket Wall Assembly 11-13 Topside Bracket Wall Assembly To Add / To Remove Panels Spare Parts &... -
Page 3: Safety Information
SAFETY INFORMATION GENERAL Read this instruction manual carefully and keep it in a safe place for future reference. The correct use and maintenance of this product is essential. MAINTENANCE Regularly check that the product is functioning correctly, lubricate hinges and moving components. Tighten and adjust mounts to ensure secure smooth operation. -
Page 4: Warnings
WARNING • To prevent serious injury or death, securely install gate or enclosure and use according to manufacturer’s instructions. • Incorrect installation can be dangerous. • Danger to older children if climbing over the barrier. • Do not use the safety barrier if any components are damaged, missing or disassembled. - Page 5 WARNING • This safety barrier has a ‘stay open’ feature. • Always check that the safety barrier is correctly closed. • Use only with the locking/latching mechanism securely engaged. • Never use with a child able to climb over or dislodge/ open the gate or enclosure.
-
Page 6: Mountings / Tools Required
SAFETY INFORMATION MOUNTINGS Gate must be installed in a structurally sound opening. Ensure mounting surface (wall, door, stair posts, etc.) is strong, rigid and has an even surface. Note: If the safety barrier is used at the top of the stairs, it should not be positioned below the top level. - Page 7 SAFETY INFORMATION Select the appropriate fixing method from the list below. HARD WALL MOUNTING BRICK / CONCRETE FOR INSTALLATION Wood Screws Anchor 1. Drill 5mm (3/16”) 2. Clear Hole 3. Insert Anchor & Tap 4. Tighten slowly Pilot Hole WOOD MOUNTING FOR INSTALLATION Wood Screws 2.
-
Page 8: What's In The Box
WHAT’S IN THE BOX PARTS UNDERSIDE TOPSIDE 2 x Barrier Panels 1 x Gate Panel... - Page 9 WHAT’S IN THE BOX 1 x Top Underside 1 x Top Topside Wall Bracket Wall Bracket 2 x Lower Wall Bracket 1 x Top Cap 1 x Bottom Cap 8 x Anchors 8x 25mm (1”) Screws 4 x Corner Tubes If any parts are missing do not attempt to use your Extra Wide Barrier.
-
Page 10: Installation
INSTALLATION Barrier Placement & Configuration Suitable placement & configurations of Playpen/Barrier Install Barrier a minimum CAUTION: of 60cm (25.5”) away from fireplace. *Playpen Configuration *Configured with x3 extra panels. *Configured with x3 extra panels. -
Page 11: Underside Bracket Wall Assembly
INSTALLATION Step 1. Underside Bracket Wall Assembly Place the Lower Wall Bracket over Corner Tube and put the Corner Tube into the Top Underside Wall Bracket. Put the Top Underside Wall Bracket into the top of the Barrier Panel and the bottom of the Corner Tube into the Top Cap on the bottom of the Barrier Panel, then into the Bottom Cap. - Page 12 INSTALLATION Step 2. Mark screw hole postions for the Top Underside Wall Bracket and Lower Wall Bracket. Disassemble Corner Tube and Barrier Panel from Top Underside Wall Bracket and Lower Wall Bracket. Screw in Top Underside Wall Bracket and Lower Wall Bracket. Install Wall Brackets on an even surface NOTE: to ensure Playpen/ Barrier is secure.
- Page 13 INSTALLATION Step 3. Reassemble Barrier Panel by connecting to the Top Underside Wall Bracket. Place Corner Tube through the Lower Wall Bracket, pull Corner Tube up and slide into the Top Underside Wall Bracket. Then place Corner Tube down into the Top Cap on the bottom of the Barrier Panel.
-
Page 14: Topside Bracket Wall Assembly
INSTALLATION Step 4. Topside Bracket Wall Assembly Place the Lower Wall Bracket over Corner Tube and slide Corner Tube up into the Barrier Panel and then into the Top Topside Wall Bracket. Follow Step 2 from Page 12 to mark position. Then reassmble and put the Top Cap on the bottom of the Barrier Panel and slide Corner Tube down into the Top Cap. -
Page 15: To Add / To Remove Panels
INSTALLATION To Add Extra Panels Align opposite ends of panels, place the Corner Tube into the top hole first, then pull the Corner Tube up and place the bottom of the Corner Tube into the Top Cap hole on the bottom of the Barrier Panel. -
Page 16: Spare Parts & Accessories
INSTALLATION Spare Parts & Accessories Scan the QR Code to view the full range of Spare Parts & Accessories including; Additional Panels, Additional Gates, Stability Clips and Wall Mounting Sets. Optional Extension - Playpen For larger openings, join with the #2747 3-In-1 Playpen/ Barrier to extend the barrier by an additional 6 panels (Including x1 gate). -
Page 17: Playpen Assembly
INSTALLATION Playpen Assembly 1. Align the Gate Panel and Barrier Panel together. Place the Corner Tube into the top hole first, then pull the Corner Tube up and place the bottom of the Corner Tube into the Top Cap hole on the bottom of the Barrier Panel. Align arrow with hexagon icon. -
Page 18: Operation
OPERATION HOW TO OPEN Slide Using one hand, place thumb on the button and grip Gate Panel with fingers. Slide button and lift Gate Panel. Lift Open gate in either direction. When released gate will swing closed automatically. 90° To enable stay open feature, open gate to a 90°... -
Page 19: Cleaning Instructions
CLEANING INSTRUCTIONS Simply use a soft damp cloth to wipe Playpen/Barrier, dry after cleaning. Do not use chemical or abrasive cleaners. -
Page 20: Support
SUPPORT WARRANTY CERTIFICATE Congratulations! You have made an excellent choice of this quality product. Our commitment to quality also includes our service. Should you, contrary to expectations, experience defects due to manufacturing faults, we will provide you with a warranty against defects as follows: WARRANTY The product is guaranteed to be free from from defects in workmanship and parts for a period of 12 months from the date of purchase. -
Page 21: Warranty Card
SUPPORT WARRANTY CARD DETAILS: Extra Wide Barrier PRODUCT NAME: White 2748 PRODUCT NUMBER: YOUR NAME: ADDRESS: PHONE: EMAIL: DATE OF PURCHASE: LOCATION OF PURCHASE: We recommend that you keep a copy of your receipt, showing the date of purchase, with this warranty certificate and keep for your reference. - Page 22 Scan the QR code for Live Chat Support or visit: permachildsafety.com/contact-us Perma Child Safety @permachildsafety...
