Wolf Steel DHMFG3850 Installation Manual

Ducted heat management
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

NATURAL GAS MODELS:
These installation instructions MUST be used in conjunction with the Vector™ / Luxuria™ installation manuals.
PROPANE GAS MODELS:
SAFETY INFORMATION
WARNING
!
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
- Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity of
this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not
use any phone in your building.
Immediately call your gas supplier from a
neighbour's phone. Follow the gas
supplier's instructions.
If you cannot reach your gas supplier, call
the fi re department.
- Installation and service must be
performed by a qualifi ed installer, service
agency, or the supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless
a certifi ed kit is used.
INSTALLER:
Leave this manual with the appliance
CONSUMER:
Retain this manual for future reference
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030
$10.00
ADD PRODUCT CODE HERE (TRADE GOTHIC LT STD FONT)
ADD MANUAL TITLE
INSTALLATION MANUAL
discharge opening
INTERTEK
Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com
DUCTED HEAT MANAGEMENT
Ducted
Heat
Management
front
ADD PRODUCT IMAGE
CERTIFIED TO THE CANADIAN AND AMERICAN NATIONAL STANDARDS:
CSA 2.22 AND ANSI Z21.50 FOR VENTED DECORATIVE GAS APPLIANCES
CERTIFIED TO THE CANADIAN AND AMERICAN NATIONAL STANDARDS:
IF INSTALLATION + OPERATION, ADD SERIAL
CSA 2.22 AND ANSI Z21.50 FOR VENTED DECORATIVE GAS APPLIANCES
FOR USE WITH VECTOR™ /
CSA /
LUXURIA™ MODELS ONLY
BARCODE LABEL ON THE OWNER'S MANUAL"
LOGO
Product Name / Code
(MUST use title from Price Book)
ADD ____ ILLUSTRATED
FOR INDOOR USE ONLY
FOR INDOOR USE ONLY
NUMBER LABEL HERE
IF SEPARATE MANUALS, ADD "PLACE
W415-2968 / B / 04.30.21
ENGLISH
FRENCH PG. 19
Ducted
Heat
Management
side discharge
opening(s)

Advertisement

Table of Contents
loading

Summary of Contents for Wolf Steel DHMFG3850

  • Page 1 LUXURIA™ MODELS ONLY BARCODE LABEL ON THE OWNER’S MANUAL” LOGO Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com W415-2968 / B / 04.30.21...
  • Page 2: Table Of Contents

    The information throughout this manual is believed to be correct at the time of printing. Wolf Steel Ltd. reserves the right to change or modify any information within this manual at any time without notice. Changes, other than editorial, are denoted by a vertical line in the margin.
  • Page 3: General Information

    general information 1.0 general information WARNING • The Ducted Heat Management (DHM) kit MUST be installed during the framing of the appliance BEFORE gas is installed. • All wiring should be done by a qualifi ed electrician and shall be in compliance with local codes. In the absence of local codes, use the current CSA22.1 Canadian Electric Code in Canada or the current National Electric Code ANSI/NFPA NO.
  • Page 4: Installation Planning

    Front Side Ducted Side Installation Manifold Front Grill Kit Manifold Kit Plate Kit Sleeve Kit Sleeve Kit Vent Kit Grill Kit Type (DHMFG3850) (DHMF3850) (DHMTP3850) (DHMFS3850) (DHMSS) (DVK) (DHMSG) (DHMS) Front discharge Manifolds Side discharge Manifolds FOR USE WITH 62” AND 74” LINEAR (LV / LVX) MODELS...
  • Page 5: Kit Components

    Wood screws grill kit components When the appliance is installed with the front or side discharge, an grill kit is available to fi nish your installation. Front grill kit (DHMFG3850/6274) Side grill kit (DHMSG) 2 x Side 1 x Front grill grills W415-2968 / B / 04.30.21...
  • Page 6: 3.0 Rough Framing

    3.0 rough framing WARNING • *LV MODELS (w/ DHM) ONLY: The rear standoffs MUST be fl attened to reduce the framing depth from 20 1/8” to 18”. • All discharge air opening(s) / grill(s) MUST be 6’ away from any sprinkler systems. •...
  • Page 7 rough framing Front discharge (single-sided) Side discharge (single-sided) 38” models 50” models 62” models 74” models 18” for single-sided | 16 3 1/6” for see-thru 53 13/16” 65 13/16” 77 13/16” 89 13/16” Optional - Appliance does not need to be elevated above fl oor 73”...
  • Page 8 rough framing single-sided recessed WARNING • When using DHM, power and A/V cables being run through the enclosure must maintain a 7” clearance from the top of the collector box and a 3.5” clearance from all other ducting and venting components. Conduit is also required, but high temperature conduit is recommended.
  • Page 9: Sleeve Installation

    rough framing sleeve installation 1. Slide the sleeve into the framed opening from inside until the back side of the sleeve hits the vertical stud. 2. For front discharge: Install wood screws (quantities vary by model size) through the dimples along the top of the sleeve [A] (see Fig.
  • Page 10: Manifold Installation

    rough framing manifold installation Type 1 1. Slide the manifold into the back of the sleeve (step A) until the slots engage the top tab in the sleeve (step B) (see above). Some components and framing hidden for clarity. SLOT TOP TAB SLEEVE MANIFOLD...
  • Page 11: Ducting Installation

    rough framing ducting installation Type 1 1. Attach the ducting to the manifold using the screws provided (see below). 2. Repeat on opposite side/ends. Front discharge note: When installing the manifolds for front discharge, the manifolds must be installed at both ends of the sleeve leaving the middle section open.
  • Page 12: Appliance Pre-Installation

    appliance pre-installation 4.0 appliance pre-installation knockout plate removal Before starting the DHM installation, remove the safety barrier. Refer to “safety barrier installation/removal” section in the appliance installation manual. WARNING • Both sets of knockouts MUST be removed when using DHM. •...
  • Page 13: Collector Box Installation

    appliance pre-installation collector box installation Type 1 note: Screw locations With the appliance in place, vary by model size it is best to install appliance x 6 per collector box venting before adding the vent shield and collector boxes. Secure collector boxes to the appliance using screws provided.
  • Page 14: High Limit Switch Installation (Lv's Only)

    appliance pre-installation high limit switch installation (LV’s only) WARNING • High Limit Switch installation is MANDATORY. Failure to correctly install will cause a fi re hazard. Plug with spade connectors Wire Harness “X4” 1.) Remove jumper plug from control board (marked 2.) Replace X4 connector, with spade connector “X4”) and install plug with spade connectors to the provided in kit.
  • Page 15: Finish Framing

    5.0 fi nish framing fi nish framing WARNING • Enclosure top MUST be installed 3” from discharge opening. Enclosure ceiling required if the discharge opening is more than 3” from the enclosure top. MUST be installed 4’ from combustibles. • All discharge air opening(s) / grill(s) Flush - front discharge Flush - side discharge...
  • Page 16: Finishing

    fi nish framing 6.0 fi nishing sleeve extension installation Type 1 1. Loosen screws and slide the extension out until its fl ush with the fi nish material. 2. Tighten screws. Not extended Fully extended 1/2” min.* 1/2” min.* Sleeve Sleeve extension extension...
  • Page 17: Clearances Around The Appliance

    fi nishing clearances around the appliance With DHM, you can fi nish the appliance with any combustible materials. Discharge opening must be located out of reach of the user. Discharge opening must not be restricted by furnishings or decor. WARNING •...
  • Page 18 WOLF STEEL LTD. 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 103 Miller Drive, Crittenden, Kentucky, USA 41030 7200 Trans Canada Highway, Montreal, Quebec, Canada H4T 1A3 Tel: 1-866-820-8686...
  • Page 19 IF SEPARATE MANUALS, ADD “PLACE LOGO BARCODE LABEL ON THE OWNER’S MANUAL” SEULEMENT Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Téléphone 1(866)820-8686 • www.napoleon.com • hearth@napoleon.com $10.00 W415-2968 / B / 04.30.21...
  • Page 20 L’information contenue dans ce manuel est jugée correcte au moment de l’impression. Wolf Steel Ltée. se réserve le droite de modifi er ou de modifi er toute information contenue dans ce manuel à tout moment sans préavis.
  • Page 21: Information Générale

    information générale 1.0 information générale AVERTISSEMENT • L’ensemble de Gestion Thermique De Conduits (DHM) DOIT être installé pendant l’installation de l’appareil AVANT que le gaz est installé. • Tous câblage doit être effectué par un électricien qualifi é conformément aux codes locaux. En l’absence de codes locaux, utilisez la version courante du Code Canadien de l’Électricité...
  • Page 22: Planification De L'installation

    Manche de Grille Collecteur Collecteur Manche Grille Avant d’installation Terminaison Avant Conduites du Côté Avant du Côté du Côté (DHMFG3850) (DHMTP3850) (DHMFS3850) (DVK) (DHMSG) (DHMF3850) (DHMS) (DHMSS) Décharge avant avec Collecteurs Décharge du côté avec Collecteurs POUR UTILISATION AVEC LES MODÈLES LINÉAIRE 62” ET 74” (LV / LVX)
  • Page 23: Composants Des Ensembles

    Lorsque l’appareil est installé avec le décharge avant ou du côté, un ensemble de grille est disponible pour fi nir votre installation. Ensemble de grille avant Ensemble de grille du côté (DHMFG3850/6274) (DHMSG) 2 x Grilles 1 x Grille avant du côté...
  • Page 24: Ossature Approximatif

    ossature approximatif 3.0 ossature approximatif AVERTISSEMENT • *MODÈLES LV (avec DHM) UNIQUEMENT - Les espaceurs arrière DOIT être aplati pour que la profondeur peut être réduite de 20 1/8” à 18”. • Toutes les ouvertures / grilles de décharge d’air DOIT être 6 pieds d’aucun systèmes de gicleur. •...
  • Page 25 ossature approximatif Décharge avant (un seul côté) Décharge du côté (un seul côté) Modèles 38” Modèles 50” Modèles 62” Modèles 74” 18” pour les modèles d’un seul côté | 16 3 1/6” pour les modèles voir à travers 53 13/16” 65 13/16”...
  • Page 26 ossature approximatif un côté encastré AVERTISSEMENT • Lors d’utilisez DHM, les câbles d’alimentation et A / V passant à travers l’enceinte doivent maintenir un dégagement de 7 po du haut de la boîte de collecteur et un dégagement de 3,5 po de tous les autres composants de conduits et d’évacuation. Un conduit est également nécessaire, mais un conduit à...
  • Page 27: Installation De La Manche

    ossature approximatif Type 3 installation de la manche 1. Glissez la manche dedans l’ouverture encadré de l’intérieur jusqu’à l’arrière de la manche se touche le colombage. 2. Pour le décharge avant: Installez les vis à bois (quantités varient par taille du modèle) à travers les fossettes le long de le haut de la manche [A] (voir Fig.
  • Page 28: Installation Du Collecteur

    ossature approximatif installation du collecteur Type 1 1. Glissez le collecteur dans l’arrière de la manche (étape A) jusqu’à ce qu’il s’engage la patte dans la manche (étape B) (voir dessous). Certains composant et ossature ÉTAPE A PATTE cachés pour clarté. FENTE MANCHE COLLECTEUR...
  • Page 29: Installation Des Conduites

    ossature approximatif installation des conduites Type 1 1. Attachez le conduite au collecteur à l’aide des vis fournis (voir dessous). 2. Répétez le côté/buts opposés. Décharge avant note: Lors d’installer les collecteurs pour décharge avant, les collecteurs doit être installés dans chaque extrémités de la manche en laissant la section centrale ouverte.
  • Page 30: Pré-Installation De L'appareil

    pré-installation de l'appareil 4.0 pré-installation de l’appareil enlèvement des plaques knockout Avant de commencer l’installation du système DHM, retirez la barrière de protection. Voir la section « installation / enlèvement de la barrière de protection » dans le manuel d’installation de l’appareil. AVERTISSEMENT •...
  • Page 31: Installation De Les Boîtes Collecteur

    pré-installation de l'appareil installation de les boîtes collecteur Type 1 note: Locations des vis Lors de placez l’appareil varient par taille de en place, il est préférable modèle d’installer l’évacuation de x 6 chaque boîte l’appareil avant d’ajouter le collecteur bouclier d’évent et les boîtes collecteur.
  • Page 32: Installation De L'interrupteur De Surchauffe (Les Modèles Lv Uniquement)

    pré-installation de l'appareil installation de l’interrupteur de surchauffe (les modèles LV uniquement) AVERTISSEMENT • L’installation de l’interrupteur de surchauffe est OBLIGATOIRE. Le défaut d’installer correctement l’interrupteur de surchauffe peut entraîner un risque d’incendie. Prise avec les fi ches plates Harnais de Fils “X4”...
  • Page 33: Ossature Fini

    5.0 ossature fi ni ossature fi ni Affl eurant - décharge avant Affl eurant - décharge du côté plafond plafond 3” min. 3” min. 4 1/8” 6 3/4” 6” min. 6” min. Objet Objet mural mural (cadre (cadre photo, photo, appareil, appareil, etc.)
  • Page 34: Finition

    fi nition 6.0 fi nition installation de l’extension de manche Type 1 1. Desserez les vis et glissez l’extension hors jusqu’il et affl eurant avec le matériau de fi nition. 2. Serrez les vis. Pas étendu Complètement étendu 1/2” min.* 1/2”...
  • Page 35: Dégagements Autour De L'appareil

    fi nition dégagements autour de l’appareil Avec DHM, vous pouvez terminer l’appareil avec des matériaux combustible. L’ouverture de décharge arrière doit être située hors de la portée de l’utilisateur. L’ouverture ne doit pas être obstruée par le mobilier ou la décoration.
  • Page 36 WOLF STEEL LTD. 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 103 Miller Drive, Crittenden, Kentucky, USA 41030 7200 Trans Canada Highway, Montreal, Quebec, Canada H4T 1A3 Tel: 1-866-820-8686...
