- Page 1 MERLYN Merlyn Showering Unit 8, Purcellsinch Industrial Park, Dublin Road, Kilkenny, Ireland. Tel: 00353 56 779 1555 Fax: 00353 56 779 1576 www.merlynshowering.com To download the Declaration of Performance (DOP) for this product please use the link below. https://merlynshowering.com/aftersales-support/dop-certs/...
- Page 2 Hinge Door & 2 Inline Panels With Side Panel INSTALLATION GUIDE...
- Page 3 AC34 AC35 AC36 ×1 ×1 ×1 MGVC45 MGST5X65 MG8x51PLUG Installation tool ×8 ×1 AC06 AC25SPACER ×2 ×1 A06S0046 AC14 Spacer Gasket AC13 Covercap ×2...
- Page 4 SP010SP281000 ×1 Door assembly tool AC07 8S1300511 ×1 AC10 Wall bracket Clamp Bracing bar cover cap Wall plug cover cap 4×30 screw 4mm Hex key ×2 ×4 ×2 ∅ 6&8...
- Page 5 Part No. Part No. Part No. GHSA MG8x51PLUG AC01 MGVC30A AC10 AC06 GMGHFB AC36 MGVC33A MGVC44LSET/RSET AC35 AC13 MGST5X65 GMGDPC AC14 AC34 GMGCPB AC37 AC07...
- Page 6 Step 1 IMPORTANT! Whether fitting on a tray or on a tiled Wetroom the tray or floor must be 100% level! 100% level ！ Step 2 Assemble the bottom track, corner bracket and end brackets on the tray. The gap between the ends of the track and the inside edge of the end bracket must be between 0 - 15mm, adjust the position of the track ( ) until the gap at both ends...
- Page 7 Step 3 Before assembling the brackets make sure panels are orientated the correct way. Measure hole centres from top and bottom to determine correct orientation of panel. Note the differences between the hinged fixed panel (has notch cuts for hinge) and the side fixed panel (no notch cuts).
- Page 8 Step 5 Fix the wall brackets making sure to have the wall bracket in the center of the hole in the glass. IMPORTANT ! This is critical as it is where the panel adjusts. If the brackets are not positioned in the center adjustment will be affected. INSIDE Step 6 Lift the assembled panel into the track.
- Page 9 Step 7 Remove both fixed panels and the bottom track, then drill holes with 8mm diameter masonry bit and insert wall plugs. Ensure the wall plugs are flush with the tile. MG8x51PLUG Insert wall plugs Drill holes for hinge Step 8 Place the assembled bottom track back on the tray and place the inline panel into the track.
- Page 10 Step 9 (A) Insert guide spacer to front corner of the track. (B) Fit side panel front corner first making sure edge of panel with 3M tape is tight to guide spacer. (C) Fit the inline panel and check all panels for level. (D) Fully tighten screws to the wall.
- Page 11 Step 11 11A Place bottom of panel into front track ensuring outside edge of inline panel is flush with the outside face of return panel. 11B Before you peel off the protective strip from the tape dry fit the panels ensuring outside edge of inline panel is flush to outside face of side panel.
- Page 12 Step 13 Fit hinges to inline panel ensuring that the part of the hinge which has a notch will be on the moving panel side. Moving Hinge plate with notch Panel Inline Panel To help align the hinge, place the 2mm clear PVC spacer under the hinge on the edge of the cutout.
- Page 13 Step 14 Check door opening at bottom and make sure that the distance at the top is the same. Gap top and bottom should be width of moving panel +12mm Fully tighten bracket to glass on the inline panel. Step 15 Place locating aids and spacers on threshold, one each side of opening.
- Page 14 Step 16 Lift door onto positioning aids, and retain door into position using top holding strip. SP010SP281000 INSIDE Gasket locating aids Step 17 Loosely fix back plate to hinges ensuring washers are in position and hinges are level.
- Page 15 Step 18 Ensure gap between both glass panels is equal top and bottom, then fully tighten hinge bolts. gap is equal 4mm ALKEY INSIDE gap is equal INSIDE Step 19 Remove top holding strip. To remove door positioning aids open door outwards. When positioning aids have been removed check gap beneath door is even.
- Page 16 Step 20 Left and right hand seal kits ( ) are provided, determine handing and use appropriate seal kit. Left hand model shown below. Push on longest seal between hinges onto back edge of moving panel. Take shortest seal and fit to top keeping notch to hinge. Repeat with longer bottom seal. Fit closing seal (B ) to edge of the inline panel.
- Page 17 Step 22 Measure between the edge of the inline panel and the inside edge of the side panel and cut the infill seal to this length. Apply a dab of silicone to both ends, insert to bottom profile. Note: The vertical fin should be positioned to the front of the enclosure.
- Page 18 Step 24 Fit the handle to the door. AC07 Step 25 Fix the top rails. Level the rail. Drill with 6mm masonary drill bit . Mark the centre of the MG6x30PLUG slot. Fix the wall bracket.
- Page 19 Step 26 Door adjustment To adjust door to get required contact against closing seal first support door with door locating aids. Loosen all bolts fixing both hinges to glass and move by required amount. Tighten all bolts and remove door positioning aids. Step 27 Where an angled bracing bar is fitted additional adjustment can be made by: 1) Loosen the 3 screws clamping the glass.
- Page 20 Step 28 Adjusting fixed panels If after fitting you still need adjustment to align doors etc, you can achieve this by loosening the screws fixing the bracket to the wall and the bolts clamping the bracket to the glass. Adjust the panels until the desired fit is achieved. Fully tighten all fixings. Note: If no further adjustment is needed make sure all fixings have been tightened securely.
- Page 21 Step 29 Fitting cover caps. Peel off protective strip to adhesive tape to back of cap and firmly press in position. Tip : We recommend that you place a dab of silicone to the back of the cover caps at each end of the tape. INSIDE fit wall bracket caps...
- Page 22 Step 30 Sealing your enclosure. Make sure all surfaces are thoroughly cleaned and dry before applying sealant. Only seal the outside of the enclosure(red line). Do not seal the inside. Seal vertically along the wall, along the outside edge of the bottom profile and any joins in the profile, including where the bottom track meets the end brackets.
