2x
4x
4
8
Hex Socket Head Bolt M5*25
X-axis Aluminum Profile
3
Insert the nut into
the profile, tighten
the screws
Y-R AXIS
Insert the nut into
the profile, tighten
the screws
Insert the nut into
the profile, tighten
the screws
Y-L AXIS
Insert the nut into the
profile, tighten the
screws
-5-
