How to Assemble the Machine
1x
2
Y-axis Aluminum Profile (Left)
1
No need to completely
tighten the screw. We'll
need it to install the other
profiles later.
2x
10
Button Head Socket Bolt M5*10
Y-L AXIS
-3-
2x
12
T-nut M5
No need to completely
tighten the screw. We'll
need it to install the other
profiles later.
