Metacon-Next RGS EI(1) 30 - EI(2) 60 - EW 240
Metacon-Next B.V.
Zuidbaan 450
2841 MD Moordrecht
The Netherlands
Tel. : +31 (0) 182 23 15 25
www.metacon-next.com
info@metacon-next.com
This is a manual translated into English
User Manual
Metacon-Next B.V.
Randweg 19
8304 AS Emmeloord
The Netherlands
+31 (0) 182 23 15 25
www.metacon-next.com
info@metacon-next.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RGS EI-30 and is the answer not in the manual?

Questions and answers

Related Manuals for Metacon-Next RGS EI-30

Summary of Contents for Metacon-Next RGS EI-30

  • Page 1: User Manual Art No: 89072 Rev

    User Manual Metacon-Next RGS EI(1) 30 - EI(2) 60 - EW 240 Metacon-Next B.V. Metacon-Next B.V. Randweg 19 Zuidbaan 450 8304 AS Emmeloord 2841 MD Moordrecht The Netherlands The Netherlands +31 (0) 182 23 15 25 Tel. : +31 (0) 182 23 15 25 www.metacon-next.com...

  • Page 2: Table Of Contents

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Preface ..............................3 Introduction ............................. 4 Safety............................... 5 Safety Features ............................5 Safety guidelines ............................ 6 Residual risks ............................7 Usage instructions ........................... 8 Normal use (not during fire alarm/calamity) ..................

  • Page 3: Preface

    Next only delivers a door. The installation, service and maintenance by and under the responsibility of the "specialist retailer" is taken care of. Metacon-Next only supplies CE marked doors in accordance with EN 13241 and/or EN 16034. If assembly and installation of the fire resistant door is done by third parties and changes are made to the door by the installation company, this shall be done with material supplied by Metacon-Next, registered under the serial number of the door.

  • Page 4: Introduction

    © COPYRIGHT Metacon-Next B.V. holds the copyright for this manual. All worldwide rights reserved. It is not permitted to copy, duplicate, translate, edit and store this manual or portions thereof in any electronic medium without prior written permission from the copyright holder.

  • Page 5: Safety

    Since Metacon-Next is only a manufacturer/supplier of "semi-finished products," it is the responsibility of the installation company to ensure that they work in accordance with the relevant instructions and regulations.

  • Page 6: Safety Guidelines

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 3.2 Safety guidelines  The fire resistant door may only be operated by persons who have taken note of the operating instructions. Under no circumstances may the door be operated by children or persons with reduced physical, sensory or mental capacity.

  • Page 7: Residual Risks

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 3.3 Residual risks In case of regular use:  Entrapment can occur when the fire resistant door closes upon fire alarm. The mechanical failsafe closing of the fire resistant door does not take into account the possible presence of persons.

  • Page 8: Usage Instructions

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 4 Usage instructions 4.1 Normal use (not during fire alarm/calamity) Before and during the operation of the door, the following steps should be observed;...

  • Page 9: Self-Closing Function

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 4.2 Self-closing function If the door is in the open position at the moment of "activation" by an (automated) alarm system and mains power failure, it will close automatically. This is done by means of an electric drive with a gravitational failsafe system.

  • Page 10: Installation Preparation

    BOM (Bill Of Material) of the user manual. 7.1 Essential tools for installation The required tools cannot be determined by Metacon-Next, as this depends on the installation situation. It is up to the supplier and/or installation company to determine the...

  • Page 11: Installation Instructions

    Follow the instructions of the fasteners supplied. Step 1: Mounting side guides Mount the side guides to the width according to Technical Drawing Metacon-Next. Check the width. Check that the side guides are installed parallel and level.
  • Page 12 Step 2: Mounting horizontal wall labyrint Mount the horizontal wall labyrint at the correct height according to Technical Drawing Metacon-Next. Spread the space between the horizontal wall labyrint and the guides left and right so that it is equal. Step 3: Use drilling template Place the drilling template against and on the guide as shown in the drawing below.
  • Page 13 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 3b: Mounting of brackets Remove the tensioner (motor bracket) and L-profile in order to obtain sufficient mounting space to install the rolled-up curtain.
  • Page 14 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 4a: Preparations for installation of curtain + barrel Degrease and oil the shaft journals before mounting the bearings onto them.
  • Page 15 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 4c: Mounting the curtain + barrel Check that the shaft is mounted parallel to the wall. Divide the space between the barrel and the brackets left and right.
  • Page 16 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 5: Mount the sprocket wheel On the motor side, insert the key into the shaft. Then slide the sprocket wheel onto...
  • Page 17 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 6a: Mounting of motor and tensioner (motor bracket) Check that the limit switch housing is in the correct position: it should not touch the chain.
  • Page 18 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 6b: Installation and tensioning of the chain Place the chain over the sprocket wheels and mark the required length, then remove the chain.
  • Page 19 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 7: Removing the film and lashing straps At the end of this step, the film and the lashing straps around the curtain and the pallet may be removed.
  • Page 20 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 8: Positioning the curtain in the guides Lower the bottom part of the curtain into the guides. Check that the curtain has...
  • Page 21 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 9: Installing the pressure roller Degrease and oil the shafts, then slide the adjusting rings over the shafts and tighten them by hand with the locking screw.
  • Page 22 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Installing the outer part of the guide Step 9: Install the outer part of the guide as shown in the drawing. Check the width size.
  • Page 23 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 10: Setting end positions Attention: the push buttons in the control box override all fuses and limit switches! First of all, open the roller shutter before you start setting the limit switches.
  • Page 24 Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Step 11: Checking the roller shutter Check that the CE sticker is clearly visible and corresponds to the installed door. Open and close the roller shutter twice using the film probe on the control box to check that it is working correctly.

  • Page 25: Initial Use

    Each door is provided with an identification stating the type of door and the order number and position number. In case of any malfunction, this number should be communicated to the supplier. Metacon-Next keeps a technical file in the archive with reference to the order number and position number.

  • Page 26: Storage And Transport

    To avoid condensation in the packaging, please open the packaging upon receipt. Transport is relatively easy as Metacon-Next only delivers semi-finished products. If the package weighs more than 20 kg, it must be moved with suitable lifting equipment.

  • Page 27: Appendix A: " Rgs Ei(1) 30 - Ei(2) 60 - Ew 240 - Installation Data

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Appendix A: " RGS EI(1) 30 - EI(2) 60 - EW 240 - Installation data" Door data  Order number .........

  • Page 28: Appendix B: "Rgs Ei(1) 30 - Ei(2) 60 - Ew 240 - Maintenance Instructions

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Appendix B: "RGS EI(1) 30 - EI(2) 60 - EW 240 - " Maintenance Instructions 1. □ Identify the door by means of a type of identification 2.

  • Page 29: Appendix C: "Rgs Ei(1) 30 - Ei(2) 60 - Ew 240 - Maintenance Log

    Metacon-Next B.V. RGS EI(1) 30 - EI(2) 60 - EW 240 12-07-2022 User Manual art no: 89072 Rev: 1 Appendix C " RGS EI(1) 30 - EI(2) 60 - EW 240 - Maintenance Log" Door checked* Replaced Remarks / Recommendations...
