Attaching the Deluxe Cutter Tray
Base
thumbscrew
Tray base
6. Making sure that the top of the tray rests against the cutter cover, adjust the
tray to the angle you choose.
7. Tighten the thumbscrews to secure the angle of the tray.
067548-001
Deluxe
tray
Thumbscrew
Cutter
cover
44XXT.001
