Assembly Instruction
Rianna Ribbed 2-Drawer Desk
SKU - 608144
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST COST PLUS WORLD MARKET STORE.
IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOM ER SERVICE CALL
CENTER TOLL FREE AT 877- 967-5362 FOR ASSISTANCE.
NOT FOR COMMERCIAL USE
Page 1
Advertisement
Table of Contents
Related Manuals for World Market Rianna Ribbed 608144
Summary of Contents for World Market Rianna Ribbed 608144
- Page 1 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOM ER SERVICE CALL CENTER TOLL FREE AT 877- 967-5362 FOR ASSISTANCE.
- Page 2 Component List LABEL PICTURE Left Leg Right Leg Metal Bracket Stretcher Hardware & Tool List Long Allen Bolt M6 x 30mm Short Allen Bolt M6 x 15mm Washer Ø16mm x Ø7mm Lock Washer Ø15mm x Ø9mm Allen Key Ø4mm x 110mm Page 2...
- Page 3 Assembly Preparation Before Beginning: • Unpack all hardware bags and components to ensure you have all parts- • Read instructions, cover to cover- • Have 2 adults on hand for assembly- • Do not assemble on flooring or carpet- • Assemble on a clean non-marring surface (packing foam) - •...
- Page 4 Assembly Steps Step-1 Gently pull out the drawer and insert the hand to unlock the drawer as illustrated. Now pull out the drawers completely to move on to the assembly process. Step-2 Front Place the Top (A) upside down on a padded non-marring surface. Align the pre-drilled holes on the Left Leg (B-1) to the holes on the side panel of the Top (A) as illustrated.
- Page 5 Assembly Steps Step-3 Front Align the stretcher (D) to the pre-cut slot on the Leg (B) ensuring the holes on the stretcher matches holes on the Leg. Secure connection using longer Long Allen Bolt (H1) and Washer (H3) with the help of Allen Key (T1). Do not fully tighten connection. Step-4 On the back side align the Metal Bracket (C) with the pre-drilled holes on the Legs (B) and underneath Top (A) as illustrated.
- Page 6 Assembly Steps Step-5 Fully tighten all connection using Allen Key (T1). Step-6 NOTE: Levelers can be used for adjustment if needed. Using a second person to assist you, carefully turn the desk assembly into the upright position. Gently insert the drawers to the position matching the label as shown above and turn the inner drawer lock in reverse direction following Step-1.
- Page 7 Anti-Tip Measures A. Mark the location of the hole on the wall using bracket (A) approx 1" below the top of furniture. Predrill the holes at marked location & insert wall anchors (E). Align bracket onto wall anchors & secure using long screws (B).
- Page 8 Page 8...
