Page 1
THANK YOU FOR PURCHASING OUR QUALITY PRODUCT. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT YOUR NEAREST WORLD MARKET STORE, OR CALL OUR TOLL FREE NUMBER 877-967-5362 FOR ASSISTANCE. NOT FOR COMMERCIAL USE.
Part List A: Top Frame - 1 pc B: Bottom Frame - 1 pc C: Divider Frame - 1 pc D-1: Left Side Frame F-1: Left Door Frame D-2: Right Side Frame E: Back Frame - 1 pc - 1 pc - 1 pc - 1 pc F-2: Right Door Frame...
Hardware List Description LABEL PICTURE Q.TY Cam lock Ø15 mm Cam Screw Screw M4 x 20 mm Connecting Screw M7 x 50 mm Wood Screw 4 x 50 mm Allen Bolt M6 x 20 mm Lock Washer 6 x 10.5 x 1 mm Flat Washer 6 x 16 x 1 mm Pan Head Screw M4 x 45 mm H-10...
Do not assemble on flooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until finished. In case of missing parts, please contact your nearest World Market store or our customer service call center 877-967-5362. Page 4...
Assembly Steps Step 1 (H-2) Cam Screw x 18 (T-2) Phillips Screwdriver Step 1.1: Step 1.2: Step 1.1 : Install Cam Screws (H-2) into the pre-drilled holes on Left Side Frame (D-1) and Right Side Frame (D-2) as shown. Fully tighten using a Phillips screwdriver (T-2) (not included). Step 1.2 : Place Top Frame (A) and Fixed Shelf (G) upside down onto a padded, non-marring surface.
Page 6
Step 2 (H-1) Cam Lock x 2 (T-1) Allen key Front Place Fixed Shelf (G) onto a padded, non-marring surface, oriented on its side as shown. Install Cam Locks (H-1) into the corresponding holes on Divider Frame (C) as shown. Carefully lower Divider Frame (C) down onto, making sure that the Cam Screws (H-2) installed on Fixed Shelf (G) fit up inside of Divider Frame (C).
Page 7
Step 4 (H-1) Cam Lock x 6 (T-1) Allen key Front Using a second person to assist you, rotate the assembly from Step 3 so that the FRONT faces down towards the ground as illustrated. Install Cam Locks (H-1) into the corresponding holes on Fixed Shelf (G), Top Back Rail (K) and Bottom Back Rail (L) as shown.
Page 8
Step 6 (H-6) Allen Bolt x 16 (H-7) Lock Washer x 16 (H-8) Flat Washer x 16 (T-1) Allen key Step 6.1: Install and secure Base Top Frame (O) and Base Bottom Frame (P) to one of Base Side Frame (N) using the Short Allen Bolt (H-6), Lock Washer (H-7) and Flat Washer (H-8), stacking the hardware in the order shown.
Page 9
Step 8 (H-1) Cam Lock x 6 (T-1) Allen key Front Using a second person to assist you, carefully turn the assembly from Step 7 upright. Install Cam Locks (H-1) into the corresponding holes on Left Side Frame (D-1) and Right Side Frame (D-2) as shown. Next, lower Top Frame (A) down onto the assembly, making sure that Cam Screws (H-2) installed on Top Frame (A) fit up inside of Left Side Frame (D-1) and Right Side Frame (D-2).
Page 10
Step 9 (H-1) Cam Lock x 2 (T-1) Allen key Front Install Cam Locks (H-1) into the corresponding holes on Top Back Rail (K) as shown. Secure the Top Back Rail (K) to Top Frame (A) by Cam Lock (H-1) using Allen Key (T-2) until snug. Step 10 (H-5) Wood Screw x 3 (T-2) Phillips Screwdriver...
Page 11
Step 11 (H-10) Pan Head Screw x 22 (T-2) Phillips Screwdriver H-10 Front Attach Back Panel (E) to the back of the bar assembly as shown. Secure the panel using Pan Head Screws (H-10). Tighten but do not over-tighten the screws using a Phillips Screwdriver (T-2) (not included). Step 12 (H-11) Shelf Pin x 4 H-11...
Page 12
Step 13 Opt 1: Front If you want to keep a bottle of wine, please set Removable Shelf (I) according to option 1. Opt 2: Front If you want to store other casual items, please set Removable Shelf (I) according to option 2. Page 12...
Page 13
Step 14 (H-3) Screw x 4 (T-2) Phillips Screwdriver Install Handles (H) to Left Door Frame (F-1) and Right Door Frame (F-2) as shown and secure using Screws (H-3) and fully tighten with Phillips Screwdriver (T-2). Step 15 Front Slide the hinges of Left Door Frame (F-1) onto the receiving hinges of Left Side Frame (D-1) as shown. Next, slide the hinges of Right Door Frame (F-2) onto the receiving hinges of Right Side Frame (D-2).
Page 14
Step 16 ADJUSTABLE LEVELER NOTE: Levelers can be used for adjustment if needed. Ensure that all bolts have been fully tightened. Assembly is now complete and the storage is ready for use. NOTE: Levelers can be adjusted for additional stability if needed. Page 14...
Care & Maintenance Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. Cleaner Do not place furniture in direct sunlight. Do not place furniture near heating or cooling vents. Do not write on furniture without a padded barrier to protect the surface. Do not place furniture outside.
Page 16
Anti-Tip Measures WARNING - Young children may be injured by a tipping furniture and the use of the tipping restraint is highly recommended. This Anti-Tip Kit (H-12) is only a deterrent. It is not a substitute for proper adult supervision. Manufacturer or retailer assumes no liability for improper installation or excessive loads placed on screws, brackets, or straps.
