Switch on the power supply of the
Cheyenne power unit and/or third-party
power unit.
Set an appropriate piercing frequency.
The piercing frequency must suit the
characteristics of the customer's skin,
the needle protrusion and piercing depth
when working, as well as the operating
speed.
With a Cheyenne Power Unit the piercing
frequency can be adjusted in 10 increments
using the arrow keys.
With a third-party power unit, the pierc-
ing frequency can be adjusted via the out-
put voltage: The permitted voltage range
of approx. 6 to 12.5 V equates roughly to
a piercing frequency range of 60 to 170
needle insertions per second. 10 V equates
to about 130 needle insertions per second
at idle speed. If the output voltage exceeds
about 13 V, the HAWK SPIRIT or HAWK
THUNDER switches o automatically.
6.3

Loading with ink

Immediately before use, dip the tip of the
safety cartridge in the desired color of ink
for 2 to 3 seconds with the unit running.
Avoid contact with the ink container.
The ink is picked up by the needles.
Alternatively, the ink can be filled into
the opening on the safety cartridge using
a sterile pipette. Never fill in too much
44 EN
ink so that it is not ejected through the
opening.
7 Cleaning and maintaining
the HAWK SPIRIT or
HAWK THUNDER
CAUTION
Risk of short circuits and risk of mild
electric shocks
If components of the HAWK SPIRIT or
HAWK THUNDER are dismantled and
cleaned while still powered, there is
a risk of mild electric shock and damage
to the electronics in the drive unit.
Switch o the voltage supply to your
HAWK SPIRIT or HAWK THUNDER be-
fore you begin with cleaning and main-
tenance work.
ATTENTION
Damage to drive caused by fluid
If cleaning fluid or disinfectant gets inside
the drive, this can corrode the electrical
and mechanical components.
Never immerse the drive in cleaning
fluid or disinfectant.
Never use an autoclave or an ultra-
sonic bath to clean the drive and the
connecting cable.
