Chapter 2 | Function Keys Instruction
The EasyCheck Fiber End-face Inspector features a continuous variable zoom ratio, manual
focusing, X- and Y-axis adjustable function and 400x zoom capability. Utlilizing different
inspection tips, EasyCheck can fulfill various inspections of MPO/MTP fiber connectors
including PC and APC. All the tips are external and easily interchangeable.
TOSA/ROSA Component Inspection
TOSA/ROSA Component Inspection
5
Multi-Channel Inspection
EasyCheck Function Description
1 - Focusing System
2 - Power Indicator Line
3 - High-resolution Screen
4 - MENU Button
5 - Page Up Button
6 - Page Down Button
7 - Image Capture Button
8 - Adapter Tip
9 - Dust Covers
10 - Focusing Ring
LightWave EasyCheck Fiber Optic End-face Inspector
1
2
3
4
5
6
7
8
9
10
