LightWave EasyCheck Fiber Optic End-face Inspector

Chapter 1 | Introduction

Thank you for purchasing your new LightWave EasyCheck Optical End-face Inspection
System. We are confident it will provide you with years of superb service, reliability, and
accuracy.
The EasyCheck EC400KC features a continuous variable zoom ratio, manual focusing, X and
Y-axis adjustable function and 400x zoom capability.
EasyCheck combines a compact design with enhanced functionality. Replacing the
traditional combination of a microscope and monitor, users can simply connect power and
begin operation. EasyCheck helps you save time and space, and improve productivity.
Advanced coaxial illumination permits easy detection of fine defects on the end-face of the
fiber connector. The conjunction with a dust-proof, high-resolution image sensor, an 8"
black-and-white digital TFT display clearly shows all details of the fiber end-face.
EasyCheck is equipped with MTP/MPO precision tips for inspection of cables with or without
housings. The high concentricity provides an ideally centered image when installing different
tips. The ceramic casing tips have nearly infinite life and the image will not deviate from
center due to extended use. The fiber End-face image can be captured at any time and
stored on a standard SD flash memory card.
Durability & Value
Durability is one of the most important factors to consider when evaluating inspection
equipment. Every EasyCheck unit and component comes from considerable design and
selection processes. The outstanding performance makes inspection a pleasure and the low
price and low failure rate give users real benefits.

Design Concept

Easycheck combines the compact appearance with enhanced functionality. Integrated
1
design results in smaller size and more convenient operation. Users simply connect the power
cable to the unit to start inspections. You no longer need to worry about the complicated cable
between monitor and microscope. Easycheck helps you save time and space, and improve
productivity.

Unrivaled Image Quality

The optical amplification system for coaxial illumination makes even the finest defects in the
endface of fiber connector clearly visible. The high-resolution image sensor, along with 8"
black-and-white digital TFT display clearly shows all details of the fiber endface, ensuring
reliability of inspection results.

Convenience

Our engineers designed the focus ring on the EasyCheck for smooth focusing. External
adapter tips make inspections of numerous connector types quick and simple.

Dust-proof

Dustproofing has been incorporated within the focusing system. Even working in dirty
environments will not affect the focus performance.
External Adapter Tip
Precise Optical-Mechanical
Alignment Structure
LightWave EasyCheck Fiber Optic End-face Inspector
Dust-Proof Cover
Focus Ring
