Quick Start
Guide
700 Color
CDMA
Radio
Setup

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 760 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec 760

Summary of Contents for Intermec 760

  • Page 1 Quick Start Guide 700 Color CDMA Radio Setup...
  • Page 2 Intermec. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. E 2004 by Intermec Technologies Corporation. All rights reserved.

  • Page 3: Table Of Contents

    ......Preparing to Install Watcher Methods for Loading Files to Your 760 Mobile Computer ..... .
  • Page 4 Steps for Using WAN Commuicator Microsoft Phone Application for CDMA Radios ......Activation and Data Provisioning (Sprint) .

  • Page 5: Introduction

    S Uses PPC Activation Wizard for activation. S Have voice capability for applications in the U.S. and Canada. If you have a 760 Color Mobile Computer continue on the next page. If however you using a 761 Color Mobile Computer go to page 25.

  • Page 6: Cdma Carriers

    Start Menu→Settings→System Ta- b→Utilities→Registry Save. Uncheck the “Enable Registry Save” box. 2 Cold Reset 760 Mobile Computer. Do this by re- moving the battery pack and pressing the Reset button in the bottom of the battery compartment. 3 Go through normal Pocket PC set-up (i.e. Align Screen etc.).

  • Page 7: Methods For Loading Files To Your 760 Mobile Computer

    4 Important! Set the Date and Time. Methods for Loading Files to Your 760 Mobile Computer There are two methods to load the file on your 760 Color Mobile Computer. S Using a Storage Card or CompactFlash card S Download file via ActiveSync on to your 760 Color...

  • Page 8: Download Files Onto Your Mobile Computer Method

    1 Obtain software from http://www.intermec.com/ developersupport 700 Color Support → Software Upgrades → Other 700 Color Downloads. 2 Download software to your 760 Mobile Computer. The file can be placed at any location on your mo- bile computer just ensure you remember where you placed it.

  • Page 9: Activation

    S It is a third party application that is unaware of certain power management methods used in your 760 Mobile Computer. Therefore, it consumes more power than necessary. S The application size consumes memory that would be better used for your application data.
  • Page 10 This is determined by your application and the services your carrier offers. After the ESNs for all the 760 Mobile Computers have been provided to the carrier and the carrier has established the accounts, you will be provided with the lock codes and telephone numbers needed to complete the activation process.
  • Page 11 S ESN of the modem S Lock/Activation Code (may be termed one of the following): MSL - Master Subsidy Lock OTSL - OneTime Subsidy Lock SPC - Service Provisioning Code OTKSL - One Time Key Subsidy Lock S SID (System ID) S NID (Network ID) S User Name S Password...

  • Page 12: Sprint Activation And Data Provision

    S Ensure you have the correct 760 Mobile Computer with the appropriate ESN. S Ensure you have 80% CDMA signal strength. S If your 760 Mobile Computer has not been pre- viously activated, Watcher automatically starts the Activation Wizard. 2 Enter the MSL or lock code received from Sprint.
  • Page 13 3 Enter the phone number (MIN) and MSID re- ceived from Sprint. Sometimes these numbers are the same. 4 After entering the phone number and MSID, the modem resets. Watcher displays the following two screens. Note: If the “searching for SB555” screen does not proceed to the next screen after 30-40 seconds, warm restart your mobile computer.
  • Page 14 5 If data provisioning does not start automatically, select it from the Admin menu. 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 15 6 Answer ’Yes’ to proceed wth data provisioning. S Activation over the air typically takes 1-10 minutes. 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 16: If Data Provisioning Fails

    S Manual activation is beyond the scope of this guide, therefore, go to Intermec Knowledge Central (http://www.intermec.com→Service and Sup- port→Knowledge Central) The article (number 5749) is titled How to Manually Activate a Sprint CDMA WAN Radio in the 760 Device. 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 17 7 Once Data Provisioning is complete, the screen reads “Provisioning complete”, 8 Test the data connection by tapping on the “con- nect” button to make a data connection to the net- work. Watcher progresses through the following two screens. Once you see the second screen you know that your mobile computer has successfully connected to the 1XRTT network.
  • Page 18 Watcher is intended for activation purposes only. Intermec recommends using the following for establishing and maintain- ing connection to the WAN radio. S Custom application using Intermec’s WWAN Toolkit API S WAN Communication Program S Custom customer application using Connection...

  • Page 19: Verizon Automated Activation Process

    Verizon Automated Activation Process Note: This process takes approximately 60 seconds. 1 Start the Watcher program and select Automated Activation click next. Note: You must be in Verizon’s coverage area to activate your mobile computer. Your mobile computer should be activated in the location where it is intended to be used.
  • Page 20 3 The activation process starts automatically. 4 You will see a series of unlock codes on your screen. 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 21 5 Continuation of activation process. 6 Commit OK and Programming OK is the final result of a successful activation. 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 22 Your unit is now successfully activated. 9 Uninstall the Watcher program by cold restarting your mobile computer. Watcher is intended for activation purposes only. Intermec recommends using the following for establishing and maintain- ing connection to the WAN radio. 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 23: Verizon Username And Password, Information

    S Custom application using Intermec’s WWAN Toolkit API S WAN Communication Program S Custom customer application using Connection Manager Interface Verizon Username and Password, information S Username for Verizon is the 10-digit phone num- ber@vzw3g.com. S The password is vzw.

  • Page 24: Telus And Bell Mobility Activation

    ESN begins with 099. S SID for Telus is 16422 Steps for Using WAN Communicator Refer to the “WWAN Communicator User’s Guide” p/n: 074250 (http://www.intermec.com, click support then manuals, and specify product). 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 25: Microsoft Phone Application For Cdma Radios

    Microsoft Phone Application for CDMA Radios Note: This is for 761 Computers PPC Phone Edition. With the WAN radio module installed in your 761 Computer, you can send and receive telephone calls. Use the speaker on the back of the computer as your earpiece and use the connector on the bottom of the computer for your mouthpiece.
  • Page 26 From the Phone application, tap Tools > Activation Wizard. 2 Have your activation code, phone number (MDN), and MSID information ready before you tap Next to continue. You can get this information from your network provider. 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 27 3 Enter your 6-digit activation code, then tap Next to continue. 4 Enter your phone number and MSID from Sprint, then tap Next to continue. 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 28: Phone Application

    5 The application prompts whether the information entered is correct. If so, tap Yes to continue, other- wise tap No to return to the MSN and MSID screen. 6 Note that voice service is available immediately. Data service take a minimum of four hours of ac- tivation before you can use the service.
  • Page 29 Tap the appropriate keys to enter a telephone number, then tap Talk to dial the number. Tap End to “hang up” the phone. Tap to backspace one digit. Tap to dial the phone number shown above the keypad. Tap to select a previously dialed number.

  • Page 30: Speed Dial

    Speed Dial Tap Speed Dial to select a telephone number with which the 741, 751, or 761 Computer is to dial auto- matically. To add to this list, use the Contacts applica- tion. See Chapter 2, “Windows Mobile 2003,” for more information about the Contacts application.
  • Page 31 S Tap Tools > Activation Wizard to access the wiz- ard with which to activate your 761 Computer. Be sure to have an activation code, a phone number, and MSID information ready. See page 25 for in- structions on using this wizard. 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 32: Phone Settings

    S Tap Tools > Send SMS tab to access the Inbox application and send an SMS (Short Messaging Service) message. Be sure to have an SMS number ready to send the message — this is usually the mo- bile phone number. See Chapter 2, “Windows Mo- bile 2003,”...
  • Page 33 S Tap the Phone tab to customize your phone set- tings such as the ring type and ring tone to use for incoming calls, and the keypad tone to use when entering phone numbers. Tap Other Settings to go to the Sounds & Notifications control panel applet. Select Start >...
  • Page 34 S Tap the Data tab to either reset your connection settings for PCS Vision or update your PCS Vision profile. S If your 760 Computer is unable to make a data con- nection and it has been more than four hours since activation, you can launch data provisioning from this screen.
  • Page 35 Note: The data provisioning process can be automatically initiated by the Sprint net- work, by attempting to make a cellular line connection to the WAN before the 760 Computer is data provisioned, or by manu- ally starting the connections through this screen.
  • Page 36 S Tap the System tab to toggle between automatic or Sprint roaming and to enable the Call Guard alert when roaming. S Tap the Phone Info tab to view the phone settings. 700 Color CDMA Radio Setup Quick Start Guide...

  • Page 37: Global Services And Support

    Global Services and Support Warranty Information To understand the warranty for your Intermec prod- uct, visit the Intermec web site at http://www.inter- mec.com and click Service & Support. The Intermec Global Sales & Service page appears. From the Service & Support menu, move your pointer over Support, and then click Warranty.

  • Page 38: Telephone Support

    Outside the U.S.A. and Canada, contact your local Intermec representative. To search for your local repre- sentative, from the Intermec web site, click Contact. 700 Color CDMA Radio Setup Quick Start Guide In the U.S.A.
  • Page 39 700 Color CDMA Radio Setup Quick Start Guide...
  • Page 40 Corporate Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com 700 Color CDMA Radio Setup Quick Start Guide *962054063E* PN 962-054-063E 700 Color CDMA Radio Setup Quick Start Guide...
