Summary of Contents for Abus FUBE50011
- Page 1 FUBE50011 USER GUIDE [UK] User Guide ......9 FUBE50011...
- Page 2 Preface Dear customer, Thank you for purchasing this wireless remote control. In choosing our product, you now have a piece of equipment that is built according to state-of-the-art technology. This document refers to the V1.3 software version of the wireless remote control. This user guide contains important installation and operation information.
-
Page 3: Intended Use
However, neither the author nor ABUS Security-Center GmbH & Co. KG can be held liable for loss or damages caused by incorrect or improper use or failure to observe the safety instructions and warnings. -
Page 4: Information On The Battery
Refer to the end of the user guide for more notes and information on operating the wireless remote control. [beginning on page 48] Information on the battery The device is supplied with direct current from a 3V lithium battery. To guarantee a long service life and avoid fire and injury, please note the following: ... - Page 5 Disposal Disposal as per directive WEEE 2002/96 EC The product contains valuable raw materials. At the end of its service life, dispose of the product according to the applicable legal requirements. Within the EU, the product and its accessories must be collected and disposed of separately. Devices displaying this symbol may not be disposed of as domestic waste.
-
Page 6: Technical Data
Technical data Wireless frequency: 868.6625 MHz Transmission power: max. 10 mW (amplifier output) Range (outdoors): approx. 200 m Range (indoors): Depending on ambient conditions Power supply: Lithium battery type / CR 2450 Li-Mn 3V Operating temperature: -10° C to +40° C Humidity: max. -
Page 7: Operation
Operation Inserting or changing the battery Before the wireless remote control can be used, the battery has to be inserted. When inserting the battery, all the LED pairs light up red and green one after another which show that all the LEDs are working properly. -
Page 8: Customer Service And Support
Please consult your dealer or installer if you have any questions. Dealer/installer Consult our website for product information. ABUS Security-Center GmbH & Co. KG 86444 Affing Linker Kreuthweg 5 GERMANY www.abus-sc.com info@abus-sc.com © ABUS Security-Center GmbH & Co. KG, August 2012... - Page 9 Operation [UK] Arming the alarm system...
- Page 10 Vds konforme Verwendung VdS conformal usage [UK] When arming the system, you are not allowed to be in the controlled area. When using alarm panels which are installed regarding VdS3438 this device is not allowed for arming or disarming the panel.
- Page 11 [UK] Arming internally...
- Page 12 [UK] Arming failure...
- Page 13 [UK] Disarming...
- Page 14 [UK] Disarming after alarm...
- Page 15 [UK] Status query [System is armed]...
- Page 16 [UK] Status query [System is armed internally]...
- Page 17 [UK] Status query [System is disarmed]...
- Page 18 [UK] Trigger panic alarm...
- Page 19 [UK] Reception time 10 s * 20 s [UK] Default setting...
- Page 20 [UK] Switching output...
- Page 21 [UK] Empty battery...
